Ports Front: 2x USB 2.0
Rear: 4x USB 3.0, 1x DB-15 VGA video, 1x RJ-45 systems management port, 2x RJ-45 GbE
network ports, 1x DB-9 serial port
Internal: 2x SD Card slots (optional, with SD Card module), 2x M.2 SSD slots (optional, with M.2
module)
Cooling Four hot-swap system fans, 3 + 1 redundant.
Power supply Up to two redundant hot-swap 450W, 550 W, 750 W, or 1100 W High Efficiency Platinum AC Power
Supplies (all 110-240V), or 750 W High Efficiency Titanium AC Power Supply (220-240V)
Hot-swap
parts
Drives, fans and power supplies
Systems
management
UEFI, ThinkServer System Management (TSM) based on ASPEED AST2400, IPMI 2.0-compliant
baseboard management controller (BMC), and support for Lenovo XClarity Administrator. Optional TSM
Premium Upgrade software feature for remote presence. ThinkServer Deployment Manager. Lenovo
XClarity Energy Manager (activated with TSM Premium or separate license).
Security
features
Power-on and administrator password. Optional Trusted Platform Module (TCG 1.2-compliant). Chassis
intrusion switch standard on some models, not available on others.
Video Onboard Aspeed AST2400 with 16MB memory, one DisplayPort on front, one VGA on rear. Maximum
resolution: 1920x1200@60Hz
Operating
systems
supported
Microsoft Windows 8, 8.1, Windows Server 2012 R2, 2012, and 2008 R2, Red Hat Enterprise Linux 6
and 7, SUSE Linux Enterprise Server 11, VMware vSphere (ESXi) 5.1, 5.5 and 6.0
Limited
warranty
One- or three-year limited onsite service with 9x5 Next Business Day
Service and
support
Optional service upgrades are available through Lenovo Services
Dimensions
Tower form factor:
Width: 173 mm (6.8 inches)
Height: 459 mm (18.1 inches) with foot stands
Depth: 685 mm (27.0 inches) including the front door
Rack form factor:
Width: 482 mm (19.0 inches) with rack handles
Height: 173 mm (6.8 inches)
Depth: 664 mm (26.1 inches)
Weight Minimum configuration: 22 kg (48.5 lb), maximum 41.5 kg (91.5 lb)
Components Specification
