Configuration notes:
Up to one adapter for external storage is supported in the server; that is, you can select only one of
the adapters that are shown in the preceding table, if needed.
If the RAID 500 or RAID 700 PCIe adapters are used in the server, the 8885e HBA cannot be used.
The following table summarizes features of supported SAS storage controllers.
Table 17. Drive controller features and specifications summary
Feature 9280-8e 9286CV-8e 8885e*
Part number 4XB0F28645 4XB0F28646 4XB0G88714
Form factor Low profile Low profile Low profile
Controller chip LSI SAS2108 LSI SAS2208 PMC PM8063
Host interface PCIe 2.0 x8 PCIe 3.0 x8 PCIe 3.0 x8
Port interface 6 Gbps SAS 6 Gbps SAS 12 Gbps SAS
Number of external ports 8 8 8
External port connectors 2x Mini-SAS (SFF-8088) 2x Mini-SAS (SFF-8088) 2x Mini-SAS HD (SFF-8644)
Drive interface SAS, SATA SAS, SATA SAS, SATA
Drive type HDD, SSD HDD, SSD HDD, SSD
Maximum number of devices 240 240 256
RAID levels 0/1/10/5/50/6/60 0/1/10/5/50/6/60 None
JBOD mode No No Yes
Cache 512 MB 1 GB 1 GB
Cache protection Optional battery
backup (67Y2647)
CacheVault flash
backup (included)
None
FastPath None Included None
CacheCade Pro 2.0 None None** None
* In addition to eight external ports, the ThinkServer 8885e adapter has eight internal ports for internal storage connectivity (For
details, refer to the Controllers for internal storage section).
** The CacheCade Pro 2.0 feature is not supported by the 9286CV-8e RAID controller when it is installed in the TS440 server.
GPU adapters
The TS440 server supports the GPU adapter options that are listed in the following table.
Note: A GPU adapter must be configured for server models that use processors without integrated graphics;
a GPU adapter is optional for server models that use processors with integrated graphics.
Table 18. GPU adapter options
Description Part number Maximum
supported
ThinkServer 1GB NVS 315 PCIe x16 Graphic Adapter by NVIDIA 4X60G88210 1
Power supplies
