Red Hat
Red Hat Enterprise Linux Server 6.4 (x86 and x64)
Red Hat Enterprise Linux Server 6.5 (x86 and x64)
Red Hat Enterprise Linux Server 6.8 (x86 and x64)
Red Hat Enterprise Linux Server 7.0
Red Hat Enterprise Linux Server 7.1
Red Hat Enterprise Linux Server 7.2
VMware
VMware ESXi 5.1 U1
VMware ESXi 5.1 U2
VMware ESXi 5.1 U3
VMware ESXi 5.5
VMware ESXi 5.5 U1
VMware ESXi 5.5 U2
VMware ESXi 5.5 U3
Citrix
XenServer 6.2
Important: VMware ESXi support requires an Intel Xeon E3-1200 v3 processor and a PCIe RAID adapter.
The onboard RAID 100 adapter and the shared GbE port (I217LM) are not supported by VMware ESXi.
For the latest information about the specific versions and service levels that are supported and any other
prerequisites, see the Operating System Interoperability Guide: http://lenovopress.com/redposig.
Physical specifications
The TS440 has the following dimensions and weight (approximate):
Height:
Without foot stands: 430 mm (16.9 in.)
With foot stands: 445 mm (17.5 in.)
Width: 195 mm (7.7 in.)
Depth: 595 mm (23.4 in.) including the front bezel
Weight:
Minimum: 19.0 kg (41.9 lb)
Maximum: 28 kg (61.7 lb)
Operating environment
The TS440 server is supported in the following environment:
Air temperature:
Operating: 10 °C - 35 °C (50 °F - 95 °F)
Storage: -40 °C - 70 °C (-40 °F - 158 °F) in the original shipping package
Altitude: 0 m - 3,048 m (0 ft - 10,000 ft) in an unpressurized environment
Humidity:
Operating: 10% - 80% (non-condensing)
Storage: 10% - 90% (non-condensing)
Electrical:
100 - 127 (nominal) V AC; 50 Hz or 60 Hz
200 - 240 (nominal) V AC; 50 Hz or 60 Hz
Regulatory compliance
