Why is my Lenovo ThinkVision T24v-30 power indicator amber but there is no image?
If the power indicator on your Lenovo monitor is amber but there's no image, the video signal cable might be loose or disconnected from the system or monitor. Ensure the video cable is properly connected to the system. Also, the monitor brightness and contrast might be at their lowest settings. Adjust the brightness and contrast settings on the OSD menu.
What to do if my Lenovo ThinkVision T24v-30 power indicator is not lit and there is no image?
If the power indicator on your Lenovo Monitor is not lit and there is no image, ensure the power cord is connected properly and that the outlet has power. Also, power on the monitor. Try using another power cord or electrical outlet.
How to fix unacceptable image quality on Lenovo ThinkVision T24v-30 Monitor?
If the image quality on your Lenovo monitor is unacceptable, make sure the video signal cable is firmly plugged into both the system and the monitor. You may also want to select another color setting from the OSD menu. Additionally, perform automatic image setup.
What to do if lines or images are blurred on Lenovo Monitor?
If lines or images are blurred on your Lenovo monitor, or if there are horizontal or vertical lines, adjust the resolution setting of the system according to the monitor's resolution: 1920 × 1080 @ 60 Hz. Also, perform automatic image setup. When working in the native resolution, you may find additional improvements by adjusting the Dots Per In. (DPI) setting on your system.
How to fix Lenovo ThinkVision T24v-30 Monitor showing 'Out of Range'?
If your Lenovo monitor displays “Out of Range” and the power indicator is flashing white, the system is set to a display mode not supported by the monitor. If replacing an old monitor, reconnect it and adjust the display mode to within the specified range for your new monitor. If using a Windows system, restart the system in safe mode, then select a supported display mode for your computer.
Why does my Lenovo ThinkVision T24v-30 Monitor have discolored pixels?
The appearance of one or more discolored pixels is a characteristic of LCD technology and is not an LCD defect. If there are more than five pixels missing, contact the Support Center.
General| Color depth | 8 bit |
|---|---|
| Color gamut | 99 % |
| Pixel pitch | 0.274 x 0.274 mm |
| Screen shape | Flat |
| Pixel density | 93 ppi |
| Response time | 6 ms |
| Backlight type | W-LED |
| Display diagonal | 23.8 \ |
| Anti-glare screen | Yes |
| Display technology | LED |
| Native aspect ratio | 16:9 |
| Maximum refresh rate | 75 Hz |
| Response time (fast) | 4 ms |
| Viewable size, vertical | 296.5 mm |
| Contrast ratio (dynamic) | 3000000:1 |
| Contrast ratio (typical) | 1000:1 |
| Display number of colors | 16.7 million colors |
| Viewable size, horizontal | 527 mm |
| Display brightness (typical) | 250 cd/m² |
| HDMI version | 1.4 |
| USB hub version | 2.0 / 3.2 Gen 1 (3.1 Gen 1) |
| DisplayPort version | 1.2 |
| Headphone connectivity | 3.5 mm |
| USB upstream port type | USB Type-B |
| USB Type-A downstream ports quantity | 4 |
| Megapixel | 2 MP |
| RMS rated power | 6 W |
| Number of speakers | 2 |
| Compatible operating systems | Windows 10, Windows 11 |
| AC input voltage | 100 - 240 V |
| Power supply type | Internal |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 60 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 18 W |
| Pivot angle | -90 - 90 ° |
| Tilt angle range | -5 - 23.5 ° |
| Cable lock slot type | Kensington |
| Panel mounting interface | 100 x 100 mm |
| Color name | Raven Black |
| Certification | ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Flicker Free, TÜV Rheinland® Eye Comfort |
| Product color | Black |
| Package type | Box |
| Package depth | 178 mm |
| Package width | 590 mm |
| Package height | 422 mm |
| Package weight | 8500 g |
| Cables included | AC, DisplayPort, HDMI, USB Type-A to USB Type-B |
| DisplayPort cable length | 1.8 m |
Weight and Dimensions| Bezel width (side) | 2.1 mm |
|---|---|
| Depth (with stand) | 199.7 mm |
| Width (with stand) | 539.8 mm |
| Height (with stand) | 542.8 mm |
| Weight (with stand) | 6000 g |
| Bezel width (bottom) | 41.4 mm |
| Depth (without stand) | 53.9 mm |
| Height (without stand) | 363.3 mm |
| Weight (without stand) | 3900 g |
Provides general advice for safe computer usage and product installation.
Covers critical warnings and precautions for safe operation and setup.
Outlines essential safety measures for using the monitor and connected equipment.
Offers tips to enhance monitor performance and extend its operational lifespan.
Provides step-by-step instructions for safely cleaning the monitor screen and housing.
Lists all items included in the product package for initial setup.
Details the physical features and basic functions of the monitor.
Explains how to adjust the monitor's screen angle for comfortable viewing.
Details monitor adjustments for swivel, height, and vertical screen pivot.
Explains IR camera adjustment and the functions of monitor control buttons.
Describes the cable lock slot and the monitor's integrated IR camera capabilities.
Explains the monitor's built-in speakers, audio output options, and volume control.
Guides users through the process of connecting cables and powering on the monitor.
Details connecting DisplayPort and USB cables for monitor setup.
Explains connecting USB downstream ports and audio cables for enhanced functionality.
Details final power connection steps and powering on the monitor and computer.
Instructions for registering the product to receive updates and support.
Guides setting up Windows Hello face recognition for Windows 10.
Guides setting up Windows Hello face recognition for Windows 11.
Discusses ergonomic principles for comfortable and productive monitor usage.
Details optimal workspace setup and monitor placement for ergonomic viewing.
Offers advice on maintaining good posture and taking breaks for computer users.
Outlines Lenovo's commitment to accessibility and available assistive technologies.
Details the functions of monitor buttons for direct access to settings.
Guides users through adjusting settings via the On-Screen Display menu.
Describes OSD options for brightness, contrast, color, and overdrive settings.
Explains OSD settings for aspect ratio, power lock, smart features, and menu.
Explains monitor features for camera status and microphone sound suppression.
Lists supported resolutions and refresh rates for optimal display configuration.
Explains monitor power states, indicators, and power management modes.
Provides instructions for monitor care, cleaning, and detaching the base/stand.
Instructions for mounting the monitor to a wall using a VESA compatible bracket.
Provides detailed technical specifications for the monitor model.
Offers solutions for common problems like 'Out of Range' and poor image quality.
Provides solutions for issues like no image, blurred text, and discolored pixels.
Step-by-step guide for installing the monitor driver in Windows 10.
Step-by-step guide for installing the monitor driver in Windows 11.
Information on how to contact the Lenovo Support Center for assistance.
Details customer responsibilities and lists available service parts for the monitor.
Instructions for registering the product to receive updates and support.
Provides information on accessing technical support online and via phone.
Lists telephone numbers for Lenovo support in various countries worldwide.
Contains legal notices, patent information, and warranty disclaimers.
Provides information on responsible recycling and disposal of Lenovo equipment and components.
Lists product trademarks and advisories on using approved power cords and adapters.
