Lenze AC Tech SF210Y User Manual

SF01U 53
THROUGH-HOLE MOUNT DIMENSIONS FOR MODELS UP TO 10 HP (7.5 kW)
The N/A indication for dimensions F, J, and K indicate that the heatsinks for these models
have fewer mounting holes than shown in the drawing.
For mm, multiply inches listed above by 25.4.
HP
(kW)
MODEL H W A B C E F J K
1
(0.75)
SF210YF 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF210F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF410F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF510F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
1.5
(1.1)
SF215YF 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF215F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF415F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
2
(1.5)
SF220YF 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF220F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF420F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
SF520F 7.72 6.80 2.76 2.76 6.00 2.69 N / A N / A N / A
3
(2.2)
SF230YF 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
SF230F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
SF430F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
SF530F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
5
(3.7)
SF250YF 9.59 11.14 5.06 4.60 10.14 3.63 N / A 2.32 2.32
SF250F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
SF450F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
SF550F 7.72 8.54 3.80 3.46 7.74 2.69 N / A 1.72 1.75
7.5
(5.5)
SF275F 11.59 11.14 5.06 4.60 10.14 4.63 2.31 2.32 2.32
SF475F 9.59 11.14 5.06 4.60 10.14 3.63 N / A 2.32 2.32
SF575F 9.59 11.14 5.06 4.60 10.14 3.63 N / A 2.32 2.32
10
(7.5)
SF2100F 15.59 11.14 5.06 4.60 10.14 6.63 3.31 1.94 2.32
SF4100F 11.59 11.14 5.06 4.60 10.14 4.63 2.31 2.32 2.32
SF5100F 11.59 11.14 5.06 4.60 10.14 4.63 2.31 2.32 2.32
