54 SF01U
THROUGH-HOLE DRAWING FOR 15 HP (11 kW) AND 20 HP (15 kW) MODELS
This drawing applies to the following models only: SF2150F, SF4150F, SF5150F, SF4200F,
and SF5200F.
THROUGH-HOLE CUTOUT DIMENSIONS FOR 15 HP (11 kW) & 20 HP (15 kW)
MODELS
HEATSINK
0.24 (6)
L
M
PANEL
CUTOUT
0.63 (16)
(left & right)
M
11.14 (283)
H
E
MOUNTING
HOLES (#8)
1.00 (25)
(top & bottom)
E
F
F
1.04
(26)
10.14 (258)
2.24
(57)
TOP
2.24
(57)
1.04
(26)
1.04
(26)
2.24
(57)
2.24
(57)
1.04
(26)
HP (kW) MODEL H E F L M
15
(11)
SF2150F 18.09 (459) 6.03 (153) 3.02 (77) 0.50 (13) 2.52 (64)
SF4150F 15.59 (396) 6.63 (168) 3.31 (84) 0.22 (5.6) 0.95 (24)
SF5150F 15.59 (396) 6.63 (168) 3.31 (84) 0.22 (5.6) 0.95 (24)
20
(15)
SF4200F 18.09 (459) 6.03 (153) 3.02 (77) 0.50 (13) 2.52 (64)
SF5200F 18.09 (459) 6.03 (153) 3.02 (77) 0.50 (13) 2.52 (64)
