Lenze 12 Series - Operating Conditions

Technical data
Weights
Operating conditions
3

12
BA 12.0028−EN 6.0
Weights [kg]: Helical−worm gearboxes / helical−worm geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
063 071 080 090 100 112 132 160
52..04 −−− −−− −−− −−− −−− −−− −−− −−−
52..05 < 20 < 25 < 30 −−− −−− −−− −−− −−− < 15
52..06 −−− < 35 < 35 < 45 −−− −−− −−− −−− < 25
52..08 −−− < 55 < 55 < 65 < 70 −−− −−− −−− < 45
52..10 −−− < 80 < 85 < 95 < 95 < 115 < 135 −−− < 70
52..12 −−− −−− < 130 < 140 < 140 < 160 < 190 < 235 < 115
Weights [kg]: Helical−bevel gearboxes / helical−bevel geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
071 080 090 100 112 132 160 180
52..04 < 55 < 60 < 70 < 75 −−− −−− −−− −−− < 40
52..05 −−− < 90 < 100 < 105 < 120 < 150 −−− −−− < 70
52..06 −−− −−− < 150 < 155 < 170 < 200 < 270 −−− < 120
52..08 −−− −−− −−− < 265 < 280 < 310 < 385 < 435 < 220
Weights [kg]: Shaft−mounted gearboxes
Type Gearbox size
08 09 10 12 14 17 18 20 24 28 35 42 45
12.410 −−− 20 30 35 55 90 −−− −−− −−− −−− −−− −−− −−−
12.420 15 20 30 50 65 100 −−− −−− −−− −−− −−− −−− −−−
12.425 −−− −−− −−− −−− −−− −−− 25 −−− 55 −−− 190 315 −−−
12.435 −−− −−− −−− −−− −−− −−− −−− −−− −−− 55 −−− −−− −−−
12.460 −−− −−− −−− −−− −−− −−− −−− 10 −−− −−− −−− −−− 15
3.2.1 Operating conditions
Ambient conditions such as temperature range, etc. are determined by the lubricant
specifications (see chapter 6.1) and the drive motor ( nameplate and Operating
Instructions for the motor).
