60
8100_A Technical description
lenze
Code level
PRG
Parameter level
Factory
Customer
<===>
settings settings
C029 Auto-adjustment for
-1-
SH + PRG
Makeauto-adjustment
actual value of the
PI controller
C034 Master current -0-
SH + PRG
Master voltage, (0 to 10V)
-0-
SH + PRG
Master current , (0 to 20 mA)
---------------------------------------------------------
-I-
SH
+ PRG Master current t (4 to 20 mA)
C036 Voltage for
xxx X 0...40X
{O.IX}
O.OXUN I
I
OC brake
C038 Preselection:
Select the desired JOGset-value with C038, then
JOGset-value
enter the JOG frequency with C039.
---------------------------------------------------------
-I- SH+ PRG JOG1set-value -1-
---------------------------------------------------------
-2-
SH+ PRG JOG2set-value
---------------------------------------------------------
.......
---------------------------------------------------------
-15
SH + PRG JOGIS set-value
--------------------------- --------------------------------------------------------- ---------
-----------
C039 Set-value for xxx Hz
-480.. .+480Hz
0.0.. .100Hz
{O.IHz}
JOGI 50.0Hz
[C038J
100.. .480Hz {1Hz}
JOG2
30.0Hz
Set-values > fdnax are l imited JOG3 O.OHz
internally to f<tnax.
JOG4 10.0Hz
JOG5 O.OHz
.. .
JOGIS O.OHz
CONTROLPARAMETERS
C040 Controller enable -0-
SH + PRG
Controller inhibited
---------------------------------------------------------
-I- SH
+ PRG Controller enabled
---------------------------------------------------------
Inhibit controller: term. 28
=OV
(or using 810288: Press STPkey)
Enable controller: term.28
= 13...30V
(or using 810288:
SH+ STP, if STPhas been
pressed before)
C0/.1Direction of -0-
SH+ PRG
Set-value not inverted
rotation
---------------------------------------------------------
-I- SH+ PRG Set-value inverted
C042Quick stop QSP
-0-
SH+ PRG
Quickstop not active
---------------------------------------------------------
-I- SH+ PRG
Quick stop active
. C043
CodeC043i s used to reset a faul t vi a the LECOM
interface (see C067)
Reset using C043 = -0-
C043 can only be reached via the lECOMinterface
C044 Enable process
-0-
SH+ PRG
Process control not active
cont rol
---------------------------------------------------------
-I-
SH
+ PRG
Process control active
C045 Enable -0- SH+ PRG Set-value
(C046) active
JOGset-value
---------------------------------------------------------
-I- SH + PRG
JOG1set-value active
---------------------------------------------------------
.....
---------------------------------------------------------
-15 SH+ PRG JOG15set-value active
