Important codes for quick commissioning
8
Commissioning
8.6
L
8.6-4
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0007
E4 E3 E2 E1
v
S
E
41
JOG1/3 DCB TRIP set DFIN1-ON
uSEr
(
c
o
n
t
)
42
QSP DCB TRIP set DFIN1-ON
(cont.)
43
CW/CCW QS P TRIP set DFIN1-ON
44
UP DOWN PAR DFIN1-ON
45
CW/CCW QS P PAR DFIN1-ON
46
M/Re PAR QSP JOG1/3
47
CW/QSP CCW/QS P M/Re JOG1/3
48
PCTRL1- OFF
DCB
PCTRL1-I-OFF
DFIN1-ON
49
PCTRL1- OFF
JOG1/3 QS P DFIN1-ON
50
PCTRL1- OFF
JOG1/3
PCTRL1-I-OFF
DFIN1-ON
51
DCB PAR
PCTRL1-I-OFF
DFIN1-ON
255 Free configuration under C0410 Only display
Do not change C0007 since settings under
C0410 can be lo st
C0010
uSEr
Minimum output
frequency
0.00 0.00
à 14.5 Hz
{0.02 Hz} 650.00
• C0010 is not ef f ective with bipolar
setpoint selection (-10 V ... + 10 V)
• C0010 only defines the analog input 1
à
S
p
e
e
d
s
e
t
t
i
n
g
r
a
n
g
e
1
:
6
f
o
r
L
e
n
z
e
^ 10.6-1
C0011
uSEr
Maximum output
frequency
50.00 7.50
à 87 Hz
{0.02 Hz} 650.00
à Speed setting range 1 : 6 for Lenze
geared motors: Setting absolutely
required f or operation with Lenze
geared motors.
C0012
uSEr
Acceleration time
main setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: frequency change 0 Hz ...
C0011
• Additional setpoint ð C0220
• Acceleration times can be activated via
digital signals
ð C0101
^ 10.7-1
C0013
uSEr
Deceleration time
main setpoint
5.00 0.00 {0.02 s} 1300.00 Reference: f re quency change C0011 ... 0
Hz
• Additional setpoint ð C0221
• Deceleration times t o be activated via
digital signals
ð C0103
^ 10.7-1
C0014
v
Operating mode 2
2 V/f charact eristic control V ~ f
(Linear characteristic with constant V
min
boost)
• Commissioning without motor parameter
identification possible
• Benefit of identification with C0148:
I
m
p
r
o
v
e
d
s
m
o
o
t
h
r
u
n
n
i
n
g
a
t
l
o
w
^ 10.3-1
3 V/f charact eristic control V ~ f
2
(Square-law characteristic with constant V
min
boost)
–
Improved smooth running at low
speed
– V/f ra t e d f re quency (C0015) and slip
(C0021) are calculated and stored.
They do not have to be entered
4 Vector control
For initial selection enter the motor data
5 Sensorless to rque control with speed limitation
• Torque setpoint via C0412/6
• Speed limit ation via setpoint 1 (NSET1-N1), if
C0412/1 is a ssigned, if not via max. frequency
(C0011)
and identify the motor parameters with
C0148
Otherwise commissioning is not
possible
C0015
uSEr
V/f rated frequency 50.00 7.50 {0.02 Hz} 960.00 • C0015 is calculated a nd stored under
C0148 when the motor parameters are
identified
• Settings applies to all possible mains
voltages
^ 8.4-1
^ 8.4-3
C0016
uSEr
V
min
boost à 0.00 {0.01 %} 40.00 à Depending on the controller
Setting applies to all mains voltages
permitted
^ 8.4-1
