C0421* Possible analog sig nals for C0421 ^
v
(cont.)
26 Output frequency normalised without s lip
(MCTRL1-NOUT-NORM)
2
14
≡ C0011
10.12-10
27 Output frequency without slip (MCTRL1-NOUT)
24000 ≡ 480 Hz
28 Act. process controller value (PCTRL1-ACT)
29 Process controller setpoint (PCTRL1-SET1)
30 Process controller output without precontrol
(PCTRL1-OUT)
31 Ramp function generator input (NSET1-RFG1-IN)
32 Ramp function generator output (NSET1-NOUT)
33 (A ) PID controller output (PCTRL1-PID-OUT)
34 (A ) Process controller output (PCTRL1-NOUT)
35 Input signal at X3/8 (Standard-I/O) or X3/1U or
X3/1I (Application-I/O), evaluated with gain
(C0414/1 or C0027) and offset (C0413/1 or
C0026) (AIN1-OUT)
1000 ≡ Maximum value analog input signal
(5 V, 10 V, 20 mA, 10 kH z)
Condition: Gain of analog input or frequency
input set to:
36 Input signal at frequency input X3/E1,
evaluated with gain (C0426) and offset (C0427)
(DFIN1-OUT)
C0414/x, C0426 = 20/C0011 [%]
37 Motor potentiometer output (MPOT1-OUT)
38 (A ) Input signal at X3/2U or X3/2I, evaluated with
gain (C0414/2) a nd of fset (C0413/2) (AIN2-OUT)
40 AIF input word 1 (AIF-IN.W1)
Setpoint to drive from communication
41 AIF input word 2 (AIF-IN.W2)
mo
u
e
o
Normalisation via AIF
50 CAN-IN1.W1 or FIF-IN.W1
Setpoints to drive from function module to
51 CAN-IN1.W2 or FIF-IN.W2
FIF
52 CAN-IN1.W3 or FIF-IN.W3
Normalisation via C
NorFIF
53 CAN-IN1.W4 or FIF-IN.W4
60 CAN-IN2.W1
61 CAN-IN2.W2
62 CAN-IN2.W3
63 CAN-IN2.W4
255 Not assigned (FIXED-FREE)
C0422* Offset analog
output X3/62
(AOUT1-OFFSET)
Standard I/O
0.00 -10.00 {0.01 V} 10.00 C0422 and C0109 are the same ^ 10.12- 4
C0422*
(A)
64
Offset analog
outputs
Application-I/O
^ 10.12-4
1 X3/62
(AOUT1-OFFSET)
0.00
-10.00 {0.01 V} 10.00 C0422/1 and C0109 are the same
2 X3/63
(AOUT2-OFFSET)
C0423*
(A)
Digital output delay
0.000 {0.001 s} 65.000 ”Debouncing” of digital outputs
(as of version application-I/O E82ZAFA ...
^ 10.13-6
1 Relay output K1
(RELAY)
0.000
Vx11)
• Switches t he digital output if the linked
2 Digital output
X3/A1 (DIGOUT1)
0.000
signal is still active after t he time set.
• Digital output reset without delay
3 Digital output
X3/A2 (DIGOUT2)
0.000
