5 Installation
5.2 Electrical installation
22
Lenze · Inverter Drive 8400 motec (PROFINET® option) · DMS 5.0 EN · 02/2019 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
•Tree via switches
[5-3] Tree topology (C =I/O controller, S = switch)
•Switch / switch
[5-4] Switch/switch topology (S = switch)
• I/O controller / I/O device
[5-5] Line topology (C = I/O controller, D = I/O device)
E94YCER006
C
S
SS
E94YCER007
SSS
E94YCER008
D D D D
C
