System bus (CAN) with Ser vo PLC & Drive PLC
Configuration (FIF interface)
5-9
l PLC-Systembus EN 1.1
5.10.3 Reaction to system bus error messages
Overview of the system bus error sources detected by the PLC and the possible settings for the
individual reactions:
Error message Possible settings / Reaction
Display Error
no.
Meaning TRIP Message Warning Error/QS
P
Off Code
CE11 122 Communication error FIF-CAN1_IN
(Time monitoring can be set via C2457/1)
ü - ü - · C2481
CE12 123 Communication error FIF-CAN2_IN
(Time monitoring can be set via C2457/2)
ü - ü - · C2482
CE13 124 Communication error FIF-CAN3_IN
(Time monitoring can be set via C2457/3)
ü - ü - · C2483
CE14 125 BUS OFF state
(too many faulty telegrams were received)
ü - ü - · C2484
· Default setting ü possible - not possible
