Technical Data
821XKlimaBA0399 3-7
3.4 Fuses and cable cross-sections
3.4.1 Single drives with 120 % overload
The table values are valid for the operation of 82XX controllers as
single drives with a matching motor and 150 % overload in pump
and fan drives.
Type
Mains input L1, L2, L3, PE/motor connection U, V, W, PE
T
y
p
e
Operation with mains filter/mains choke
Fuse F1, F2, F3 E.l.c.b. Cable cross-section
1)
VDE UL VDE mm
2
AWG
8211 M6A - B6A 1 17
8212 M6A - B6A 1 17
8213 M 10A - B10A 1.5 15
8214 M 10A - B10A 1.5 15
8215 M 20A - B20A 4 11
8216 M 20A - B20A 4 11
8217 M 32A - B32A 6 10
8218 M 32A - B32A 6 10
1)
Observe national and regional regulations (e. g. VDE/EVU)!
