Parameter setting
Parameter setting using the keypad
6
l
EDKVF9333 EN 1.0
2.2.2 Change of parameters
Tip!
Changed parameter sets must be saved, if you do not want to loose the modifications after mains
disconnection (see chapter 2.2.3).
Basic procedure
1. Change to the code level from the menus using the arrow keys
Y
,
B
,
A
or
"
to the c ode level.
”Code” is displayed.
2. Select C0810/1 using
Y
or
B
select code or subcode.
3. Change to the parameter level using PR G .”Para” is displayed.
4. Select C0810/1 using
A
or
"
move the cursor (small, black bar) under the number to be
changed.
5. Select C0810/1 using
Y
or
B
change number.
6. Repeat 4. and 5. to change other numbers, if ncessary.
7. Accept parameters. The way the controller accepts the modified parameters is shown in the
LCD display in fr ont of the parameter:
Display in front of the parameter Controller uses the new value
Immediately during the change
SH+PRG
after pressing SH+PRG. Confirmation: ok in the display
SH+PRG Press STOP to inhibit the controller.
Press S HIFT + PRG. Confirmation: ok in the display
Press R UN to enable the controller
8. Press PRG twice to go to the code level. ” Code” is displayed.
