Parameter setting
Parameter setting using the keypad
5
l
EDKVF9333 EN 1.0
Operat ing level
F rom the parameter level, you reach the operating level by pressing PRG.
•
In the operating level, additional status information and the additional display value specified
under C0004 is displayed (presetting: actual speed C0051).
– When the USER menu has been selected, the first code level of the USER menu will be
displayed in the first line.
•
Additional information is displayed according to the following priority list:
Priority Display Meaning
1 GLOBAL DRIVE INIT Initialisation or communication error between keypad and controller
2 XXX - TRIP active TRIP (contents of C0168/1)
3 XXX - MESSAGE active message (contents of C0168/1)
4
Special controller states:
Switch-on inhibit
5
Source for controller inhibit (the value of C0004 is displayed a t the same t i me):
STP1 Terminal X5/28
STP3 Keypad or LECOM A/B/LI
STP4 InterBus-S or Profibus
STP5 System bus (CAN)
STP6 C0040
j6
Source of quick stop:
QSP-term-Ext HIGH signal is applied at input MCTRL-QSP on the function block MCTRL
(in factory setting applied to terminals X5/E1 and X5/E2)
QSP-C0135 Keypad or LECOM A/B/LI
QSP-AIF InterBus-S or Profibus
QSP-CAN System bus (CAN)
7 XXX - WARNING active warning (contents of C0168/1)
8 xxxx Value under C0004
User menu
In some applications, specific codes must be changed often.
You can therefore establish a menu with max. 32 codes which you use frequently under C0517.
•
Thenumberbeforethecommaisthecodenumber.
•
T he number after the comma is the subcode.
•
Code-subcode combinations are allowed only once.
