Function block library
7-166

SHB9300CRV EN 2.0
7.6.52.2 JOG setpoints
l
These are fixed values which are saved in the memory.
l
JOG values can be called from the memory via the inputs NSET-JOG*x.
l
The inputs NSET-JOG*x are binary coded so that 15 JOG values can be called.
l
The decoding for the enabling of the JOG values (calling from the memory) is carried out
according to the following table:
Output signal 1st input
NSET-JOG*1
Input
NSET-JOG*2
3rd input
NSET-JOG*4
4th input
NSET-JOG*8
NSET-N 0 0 0 0
JOG 1 1 0 0 0
JOG 2 0 1 0 0
JOG 3 1 1 0 0
JOG 4 0 0 1 0
JOG 5 1 0 1 0
JOG 6 0 1 1 0
JOG 7 1 1 1 0
JOG 8 0 0 0 1
JOG 9 1 0 0 1
JOG 10 0 1 0 1
JOG 11 1 1 0 1
JOG 12 0 0 1 1
JOG 13 1 0 1 1
JOG 14 0 1 1 1
JOG 15 1 1 1 1
l
If all inputs are assigned with 0, the input NSET-N is active.
l
The number of inputs which you must assign, depends on the number of the required JOG
setpoints. A maximum of four inputs and thus 15 possibilities can be selected. The digital
signal source is assigned under C0787 and the corresponding subcode.
Number of the required JOG setpoints Number of the inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
