Configuration
7-291
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
[C1178]
1
2
3
CFG: IN1
CFG: IN2
CFG: IN3
1000 FIXED0 @ Selection list 2 Digital inputs AND7
C1179 DIS: C1178 Display of C1178
ANEG
[C0700] CFG: IN 19523 FCODE-472/3 @ Selection list 1 Input ANEG1
C0701 DIS: C0700 -199.99 {0.01 %} 199.99 Display of C0700
[C0703] CFG: IN 1000 FIXED 0 % @ Selection list 1 Input ANEG2
C0704 DIS: C0703 -199.99 {0.01 %} 199.99 Display of C0703
AOUT
[C0431] CFG: IN 5001 MCTRL-NACT @ Selection list 1 Input AOUT1
[C0432] CFG: OFFSET 19512 FCODE-109/1 @ Selection list 1 Offset AOUT1
[C0433] CFG: GAIN 19510 FCODE-108/1 @ Selection list 1 Gain AOUT1
C0434
1
2
3
DIS: C0431
DIS: C0432
DIS: C0433
-199.99 {0.01 %} 199.99 Display of C0431 ... C0433
[C0436] CFG: IN 5002 MCTRL-MSET2 @ Selection list 1 Input AOUT2
[C0437] CFG: OFFSET 19513 FCODE-109/2 @ Selection list 1 Offset AOUT2
[C0438] CFG: GAIN 19511 FCODE-108/2 @ Selection list 1 Gain AOUT2
C0439
1
2
3
DIS: C0436
DIS: C0437
DIS: C0438
-199.99 {0.01 %} 199.99 Display of C0436 ... C0438
ARIT
C0338 ARIT1 funct 1 0{1}5ARIT1 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2
4 IN1 / IN2
5 IN1/(100% - IN2)
[C0339]
1
2
CFG: IN1
CFG: IN2
1000 FIXED 0 % @ Selection list 1 Configuration arithmetic blockARIT1
C0340 DIS: C0339 Display of C0339
C0600 ARIT2 funct 1 0{1}5ARIT2 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2
4 IN1 / IN2
5 IN1/(100% - IN2)
[C0601]
1
2
CFG: IN
CFG: IN
1000 FIXED 0 % @ Selection list 1 Analog inputs of ARIT2
C0602 DIS: C0602 -199.99 {0.01 %} 199.99 Display of C0601
ARITPH
C1010 Function 1 0/1/2/3/13/14/21/22 Function of ARITPH1
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1011]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH1
C1012 DIS: C1011 -2147483647 {1} 2147483647 Display of C1011
