Configuration
7-292

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C1020 ARITPH2 funct 1 0/1/2/3/13/14/21/22 ARITPH2 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1021]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH2
C1022 DIS: C1021 -2147483647 {1} 2147483647 Display of C1021
C1025 ARITPH3 funct 1 0/1/2/3/13/14/21/22 ARITPH3 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1026]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH3
C1027 DIS: C1026 -2147483647 {1} 2147483647 Display of C1026
C1550 ARITPH4 funct 1 0/1/2/3/13/14/21/22 ARITPH4 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1551]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH4
C1552 DIS: C1551 -2147483647 {1} 2147483647 Display of C1551
C1555 ARITPH5 funct 1 0/1/2/3/13/14/21/22 ARITPH5 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1556]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH5
C1557 DIS: C1556 -2147483647 {1} 2147483647 Display of C1556
C1560 ARITPH6 funct 1 0/1/2/3/13/14/21/22 ARITPH6 function
0OUT=IN1
1 IN1 + IN2
2 IN1 - IN2
3 IN1 * IN2 / 2
30
13 IN1 * IN2
14 IN1 / IN2
21 IN1 + IN2 (no limit)
22 IN1 - IN2 (no limit)
[C1561]
1
2
CFG: IN
CFG: IN
1000 FIXED0INC @ Selection list 3 Inputs ARITPH6
