Configuration
7-293
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C1562 DIS: C1561 -2147483647 {1} 2147483647 Display of C1561
ASW
[C0810]
1
2
CFG: IN
CFG: IN
55
1000
@ Selection list 1
AIN2-OUT
FIXED0%
Analog inputs ASW1
[C0811] CFG: SET 1000 FIXED0 @ Selection list 2 Digital input ASW1
C0812 DIS: C0810 -199.99 {0.01 %} 199.99 Display of C0810
C0813 DIS: C0811 Display of C0811
[C0815]
1
2
CFG: IN
CFG: IN
1000
1000
FIXED0% @ Selection list 1 Analog input ASW2
[C0816] CFG: SET 1000 FIXED0 @ Selection list 2 Digital input ASW2
C0817 DIS: C0817 -199.99 {0.01%} 199.99 Display of C0817
C0818 DIS: C0816 Display of C0816
[C1160]
1
2
CFG: IN
CFG: IN
1000 FIXED0% @ Selection list 1 Analog inputs ASW3
[C1161] CFG: SET 1000 FIXED0 @ Selection list 2 Digital input ASW3
C1162 DIS: C1160 -199.99 {0.01 %} 199.99 Display of C1160
C1163 DIS: C1161 Display of C1161
[C1165]
1
2
CFG: IN
CFG: IN
1000 FIXED0% @ Selection list 1 Analog inputs ASW4
[C1166] CFG: SET 1000 FIXED0 @ Selection list 2 Digital input ASW4
C1167 DIS: C1165 -199.99 {0.01 %} 199.99 Display of C1165
C1168 DIS: C1166 Display of C1166
BRK
C0195 BRK1 T act 99.9 0.0 {0.1 s} 99.9 Brake-open time
Engagement time of the mechanical holding brake
l After the time elapsed under C0195, the status ”me-
chanical brake closed” is reached
C0196 BRK T release 0.0 0.0 {0.1 s} 60.0 Brake opening time
Disengagement time of the mechanical holding brake
(Technical data of brakes)
l After the time has elapsed under C0196, the status
”mechancial brake open” is reached.
C0244 BRK M set 0.00 -100.00 {0.01 %} 100.00 Holding torque of the DC injection brake
100 % = value of C0057
[C0450] CFG: NX 1000 FIXED 0 % @ Selection list 1 Configuration analog input of BRK1
[C0451] CFG: ON 1000 FIXED0 @ Selection list 2 Digital input of BRK1
[C0452] CFG: SIGN 1000 FIXED 0 % @ Selection list 1 Configuration analog input of BRK1
C0458
1
2
DIS: C0450
DIS: C0452
-199.99 {0.01 %} 199.99 Display of
C0450
C0452
C0459 DIS: C0451 Display of C0451
CAN-IN
C0136
1
2
3
DIS: CTRLWORD
DIS: CTRLWORD
DIS: CTRLWORD
Control word in DCTRL
Control word in CAN-IN1
Control word in AIF-IN
C0863
1
2
3
4
5
6
DIS: IN3 dig0
DIS: IN2 dig16
DIS: IN2 dig0
DIS: IN3 dig16
DIS:IN3 dig0
DIS:IN3 dig16
0
0
0
0
0
0
01 Display parameter
DIS: IN1 (0-15)
DIS: CAN-IN1 (digital 1-16)
