Lenze EVS9323-EK User Manual

Configuration
7-298

SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C0690 Function 1 1{1}6Comparator CMP3, compares inputs IN1 and IN2
1IN1=IN2
2IN1>IN2
3IN1<IN2
4 |IN1| = |IN2|
5 |IN1| > |IN2|
6 |IN1| < |IN2|
C0691 Hysteresis 1.00 0.00 {0.01 %} 100.00 % Hysteresis of CMP3
C0692 Window 1.00 0.00 {0.01 %} 100.00 % Window of CMP3
[C0693]
1
2
CFG: IN
CFG: IN
1000 FIXED 0% @ Selection list 1 Configuration analog inputs of CMP3
C0694 DIS: C0693 -199.99 {0.01 %} 199.99 Display of C0693
CONV
C0655 Numerator 1 -32767 {1} 32767 CONV5 Numerator
C0656 Denominator 1 1 {1} 32767 CONV5 Denominator
[C0657] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input of CONV5
C0658 DIS: C0657 -199.99 {0.01 %} 199.99 Display of C0657
C0940 Numerator 1 -32767 {1} 32767 CONV1 Numerator
C0941 Denomitator 1 1 {1} 32767 CONV1 Denominator
[C0942] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input CONV1
C0943 DIS: C0942 -199.99 {0.01 %} 199.99 Display of C0942
C0945 Numerator 1 -32767 {1} 32767 CONV2 Numerator
C0946 Denominator 1 1 {1} 32767 CONV2 Denominator
[C0947] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input CONV2
C0948 DIS: C0947 -199.99 {0.01 %} 199.99 Display of C0947
C0950 Numerator 1 -32767 {1} 32767 CONV3 Numerator
C0951 Denominator 1 1 {1} 32767 CONV3 Denominator
[C0952] CFG: IN 1000 FIXEDPHI0 @ Selection list 4 Configuration analog input CONV3
C0953 DIS: C0952 -32767 {1 rpm} 32767 Display of C0952
C0955 Numerator 1 -32767 {1} 32767 CONV4 Numerator
C0956 Denominator 1 1 {1} 32767 CONV4 Denominator
[C0957] CFG: IN 1000 FIXEDPHI0 @ Selection list 4 Configuration analog input CONV4
C0958 DIS: C0957 -32767 {1 rpm} 32767 Display of C0957
C1170 Numerator 1 -32767 {1} 32767 Numerator for CONV6
C1171 Denominator 1 1 {1} 32767 Denominator for CONV6
[C1172] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input of CONV6
C1173 DIS: C1172 -199.99 {0.01 %} 199.99 Display of C1172
CONVAD
[C1580] CFG: IN 1000 FIXED0% @ Selection list 1 CONVAD1
C1581 DIS: C1580 0 -32768 {1} 32767 Display of C1580
[C1582] CFG: IN 1000 FIXED0% @ Selection list 1 CONVAD2
C1583 DIS: C1582 0 -32768 {1} 32767 Display of C1582
CONVPHA
C1000 Division 1 0 {1} 31 Factor
[C1001] CFG: IN 1000 FIXED0INC @ Selection list 3 Configuration input of CONVPHA1
C1002 DIS: C1001 -2147483647 {1} 2147483647 Display of C1001
CONVPHD
C1480 Encoder constant 512 10 {1} 32767
C1486
1
2
CFG: NOM
CFG: DEN
19521
19522
@ Selection list 3
FCODE-474/1
FCODE-474/2
1. Stretching factor numerator, input limited to
 1000000
2. Stretching factor denominator, input limited to + 1 to
+200000000
C1487 DIS: C1486 Display of C1486
C1488 CFG: IN 1000 FIXEDPHI-0 @ Selection list 4 Input in rpm
C1489 DIS: C1488 Display of C1488
CONVPHPH
[C1240]
1
2
CFG: NUM
CFG: DEN
1000 FIXED0% @ Selection list 1
[C1241] CFG: ACT 1000 FIXED0 @ Selection list 2
[C1242] CFG: IN 1000 FIXED0INC @ Selection list 3
