Configuration
7-299
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
C1245
1
2
DIS: NUM
DIS: DEN
-199.99 {0.01 %} 1999.99
C1246 DIS: C1241 Display of C1241
C1247 DIS: C1242 -2147483647 {1} 2147483647 Display of C1242
CONVPHPHD
C1450 CFG: IN 1000 FIXED0INC @ Selection list 3 Phase input
C1451 DIS: C1450 Display of C1450
C1452 Numerator 1 -32767 {1} 32767
C1453 Denominator 1 1 {1} 32767
CONVPP
[C1250] CFG: IN 1000 FIXEDPHI-0 @ Selection list 4
[C1251]
1
2
CFG: NUM
CFG: DEN
1000 FIXED0INC @ Selection list 3
C1253 DIS: C1250 -32767 {1 rpm } 32767
C1254 DIS: C1251 -2147483647 {1} 2147483647 Display of C1251
CSEL
C1420 Emergency off profile 0 0{1}7
1424
1
2
3
4
5
CFG: CAM*1
CFG: CAM*2
CFG: CAM*4
CFG: LOAD
CFG: EVENT
1000 FIXED 0 @ Selection list 2
1. Selection bit 0
2. Selection bit 1
3. Selection bit 2
4. Acceptance signal = LOW -> HIGH transition
5. Event profile
1425 DIS: C1424 Display of C1424
CURVE
C0960 Function 1 1{1}3Function
1Characteristic1
2Characteristic2
3Characteristic3
C0961 y0 0.00 0.00 {0.01 %} 199.99
C0962 y1 50.00 0.00 {0.01 %} 199.99
C0963 y2 75.00 0.00 {0.01 %} 199.99
C0964 y100 100.00 0.00 {0.01 %} 199.99
C0965 x1 50.00 0.01 {0.01 %} 100.00
C0966 x2 75.00 0.01 {0.01 %} 100.00
[C0967] CFG: IN 1000 FIXED0% @ Selection list 1 Characteristic CURVE1-IN
C0968 DIS: C0967 -199.99 {0.01 %} 199.99 Display of C0967
CURVEC
C1310 Cam profile selection 0 0{1}7
C1320 CFG: AIN 1000 FIXED0% @ Selection list 1
C1321 DIS: C1320 Display of C1320
C1322
9
10
11
12
CFG: HOLD
CFG: SEL-IN
CFG: REL-SEL
CFG: XRESET
1000 FIXED 0 @ Selection list 2 9: HIGH = Outputs AOUT and OUT are sto-
red; DFOUT = 0
10: Selection input AIN
G IN
LOW = AIN
HIGH = IN
C1323 DIS: C1322 Display of C1322
C1324 CFG: IN 1000 FIXED0INC @ Selection list 3
C1325 DIS: C1324 Display of C1324
DB
C0620 DB1 gain 1.00 -10.00 {0.01} 10.00 Gain dead band component DB1
C0621 DB1 value 1.00 0.00 {0.01 %} 100.00 Dead band of DB1
[C0622] CFG: IN 1000 FIXED 0 % @ Selection list 1 Configuration analog input of DB1
C0623 DIS: C0622 -199.99 {0.01 %} 199.99 Display of C0622
DCTRL
C0040 Ctrl enable 1 0{1}1Controller inhibit
0: “write”, controls the code
1: “read”, reads the controller status
