Lenze EVS9323-EK User Manual

Configuration
7-309
 SHB9300CRV EN 2.0
Code ImportantPossible settingsLCDCode Important
SelectionLenze
LCD
[C0495] Feedback n 0
0{1}4
Feedback system for the speed controller
l C0495 = 0, 1, 2 can be mixed with C0490 = 0, 1, 2
l C0495 = 3, 4 also sets C0490 to the same value
0ResolveratX7
0
R
e
s
o
l
v
e
r
a
t
X
7
1 Encoder TTL at X8
2 Encoder sin at X8
3 Absolute ST at X8
4 Absolute MT at X8
C0497 Nact-filter 2.0 0.0 {0.1 ms} 50.0
0 ms switched off
Time constant actual speed
[C0890] CFG: N-SET
5050
@ Selection list 1
NSET-NOUT
Speed setpoint input
[C0891] CFG: M-ADD 1000 FIXED0% @ Selection list 1 Configuration torque setpoint input
[C0892] CFG: LO-M-LIM 5700 ANEG1-OUT @ Selection list 1 Configuration lower torque limit
[C0893] CFG: HI-M-LIM 19523 FCODE-472/3 @ Selection list 1 Configuration upper torque limit
[C0894] CFG: PHI-SET 1000 FIXED0INC @ Selection list 3 Configuration rotor position setpoint
[C0895] CFG: PHI-LIM 1006 FIXED100% @ Selection list 1 Configuration phase controller limit
[C0896] CFG: N2-LIM 1000 FIXED0% @ Selection list 1 Configuration 2nd speed limitation value
[C0897] CFG: PHI-ON 1000 FIXED0 @ Selection list 2 Configuration switch-on signal phase con-
troller
[C0898] CFG: FLD-WEAK 1006 FIXED100% @ Selection list 1 Signal for field weakening
[C0899] CFG: N/M-SWT 1000 FIXED0 @ Selection list 2 Changeover between n and M control
[C0900] CFG: QSP 10250 R/L/Q-QSP @ Selection list 2 Control signal for release
[C0901] CFG: I-SET 1000 FIXED0% @ Selection list 1 Load I-component of the speed controller
[C0902] CFG: I-LOAD 1000 FIXED0 @ Selection list 2 Release signal to load the I-component of the speed
controller
[C0903] CFG: P-ADAPT 1006 FIXED0% @ Selection list 1 Adaptation phase controller
C0906
1
2
3
4
5
6
7
8
9
DIS: N-SET
DIS: M-ADD
DIS: LO-M-LIM
DIS: HI-M-LIM
DIS: PHI-LIM
DIS: N2-LIM
DIS: FLD-WEAK
DIS: I-SET
DIS: P-ADAPT
-199.99 {0.01 %} 199.99 Analog input signals of MCTRL
C0907
1
2
3
4
DIS: PHI-ON
DIS: N/M-SWT
DIS: QSP
DIS: I-LOAD
digital input signals
C0908 DIS: PHI-SET -2147483647 {1 inc} 2147483647 Set phase signal
l 1 rev. = 65536 inc
C0909 Speed limit 1 1{1}2Limitation of direction of rotation for the speed setpoint
1 +/- 175 %
2 0 .. +175 %
3 -175 .. 0 %
MFAIL
[C0970] CFG: N-SET 1000 FIXED0% @ Selection list 1 Speed input of the mains failure control
Setpoint path
[C0971] CFG: FAULT 1000 FIXED0 @ Selection list 2 Input mains failure detected, input for activation
[C0972] CFG: RESET 1000 FIXED0 @ Selection list 2 Reset input mains failure control
[C0973] CFG: ADAPT 1000 FIXED0% @ Selection list 1 Adaptation of P-gain of the voltage controller
[C0974] CFG: CONST 1000 FIXED0% @ Selection list 1 Adaptation of P-gain of the voltage controller
[C0975] CFG: THRESHLD 1000 FIXED0% @ Selection list 1 Restart protection when the value falls below the speed
threshold
[C0976] CFG: NACT 1000 FIXED0% @ Selection list 1 Comparison of threshold function
l Start for V
2
controller
[C0977] CFG: SET 1000 FIXED0% @ Selection list 1 Speed start value
[C0978] CFG: DC-SET 1000 FIXED0% @ Selection list 1 Setpoint DC-bus voltage
