Configuration
7-323
SHB9300CRV EN 2.0
7.10 Selection list for signal connections
The signals must be connected by entering their numbers to configure the controller via thekeypad.
Selection list 1, analog output signals (
L
)
000050 AIN1-OUT 019500 FCODE-17 020101 CAN-IN1.W1
000055 AIN2-OUT 019502 FCODE-26/1 020102 CAN-IN1.W2
000100 DFSET-NOUT 019503 FCODE-26/2 020103 CAN-IN1.W3
001000 FIXED0% 019504 FCODE-27/1 020201 CAN-IN2.W1
001006 FIXED100% 019505 FCODE-27/2 020202 CAN-IN2.W2
001007 FIXED-100% 019506 FCODE-32 020203 CAN-IN2.W3
005000 MCTRL-NSET2 019507 FCODE-37 020204 CAN-IN2.W4
005001 MCTRL-NACT 019510 FCODE-108/1 020301 CAN-IN3.W1
005002 MCTRL-MSET2 019511 FCODE-108/2 020302 CAN-IN3.W2
005003 MCTRL-MACT 019512 FCODE-109/1 020303 CAN-IN3.W3
005005 MCTRL-DCVOLT 019513 FCODE-109/2 020304 CAN-IN3.W4
005009 MCTRL-PHI-ACT 019515 FCODE-141 025101 AIF-IN.W1
005050 NSET-NOUT 019521 FCODE-472/1 025102 AIF-IN.W2
005100 MPOT1-OUT 019522 FCODE-472/2 025103 AIF-IN.W3
005150 PCTRL1-OUT 019523 FCODE-472/3
005200 REF-N-SET 019524 FCODE-472/4
005500 ARIT1-OUT 019525 FCODE-472/5
005505 ARIT2-OUT 019526 FCODE-472/6
005550 ADD1-OUT 019527 FCODE-472/7
005600 RFG1- OUT 019528 FCODE-472/8
005650 ASW1-OUT 019529 FCODE-472/9
005655 ASW2-OUT 019530 FCODE-472/10
005700 ANEG1-OUT 019531 FCODE-472/11
005705 ANEG2-OUT 019532 FCODE-472/12
005750 FIXSET1-OUT 019533 FCODE-472/13
005800 LIM1-OUT 019534 FCODE-472/14
005850 ABS1-OUT 019535 FCODE-472/15
005900 PT1-1-OUT 019536 FCODE-472/16
005950 DT1-1-OUT 019537 FCODE-472/17
006100 MFAIL-NOUT 019538 FCODE-472/18
006150 DB1-OUT 019539 FCODE-472/19
006200 CONV1-OUT 019540 FCODE-472/20
006205 CONV2-OUT 019551 FCODE-473/1
006210 CONV3-OUT 019552 FCODE-473/2
006215 CONV4-OUT 019553 FCODE-473/3
006230 CONVPHA1-OUT 019554 FCODE-473/4
006400 FCNT1-OUT 019555 FCODE-473/5
006300 S&H1-OUT 019556 FCODE-473/6
006350 CURVE1-OUT 019557 FCODE-473/7
010000 BRK-M-SET 019558 FCODE-473/8
013301 CDATA-ACTCAM 019559 FCODE-473/9
013302 CURVEC1-AOUT 019560 FCODE-473/10
013601 CSEL1-OUT
013351 CCTRL-NOUT
013352 CCTL-MOUT
013701 MSEL1-MVAL
013711 MSEL2-MVAL
