Configuration
7-324

SHB9300CRV EN 2.0
Selection list 2, digital output signals (
P
)
000051 DIGIN1 010620 NOT5-OUT 015012 MONIT-EEr
000052 DIGIN2 010650 CMP1-OUT 015013 MONIT-OC1
000053 DIGIN3 010655 CMP2-OUT 015014 MONIT-OC2
000054 DIGIN4 010660 CMP3-OUT 015015 MONIT-LP1
000055 DIGIN5 010680 PHCMP1-OUT 015016 MONIT-OH
000060 STATE-BUS 010685 PHCMP2-OUT 015017 MONIT-OH3
000065 DIGIN-CINH 010700 DIGDEL1-OUT 015018 MONIT-OH4
000100 DFSET-ACK 010705 DIGDEL2-OUT 015019 MONIT-OH7
000500 DCTRL-RDY 010750 TRANS1-OUT 015020 MONIT-OH8
000501 DCTRL-CINH1 010755 TRANS2-OUT 015021 MONIT-Sd2
000502 DCTRL-INIT 010900 FLIP1-OUT 015022 MONIT-Sd3
000503 DCTRL-IMP 010905 FLIP2-OUT 015023 MONIT-P03
000504 DCTRL-NACT=0 012000 PHINT1-FAIL 015024 MONIT-P13
000505 DCTRL-CW/CCW 012005 PHINT2-FAIL 015026 MONIT-CE0
001000 FIXED0 013000 FEVAN1-BUSY 015027 MONIT-NMAX
001001 FIXED1 013001 FEVAN1-FAIL 015028 MONIT-OC5
002000 PAR*1 013301 CDATA-SEC1 015029 MONIT-SD5
002001 PAR*2 013302 CDATA-SEC2 015030 MONIT-SD6
002002 PAR- BUSY 013303 CDATA-SEC3 015031 MONIT-SD7
005001 MCTRL-QSP 013304 CDATA-SEC4 015032 MONIT-H07
005002 MCTRL-IMAX 013305 CDATA-SEC5 015033 MONIT-H10
005003 MCTRL-MMAX 013306 CDATA-X0 015034 MONIT-H11
005050 NSET-RFG-I=0 013307 CDATA-X> XMAX 015040 MONIT-CE1
005200 REF-OK 013308 CDATA-X<0 015041 MONIT-CE2
005201 REF-BUSY 013309 CDATA-BUSY-LENx 015042 MONIT-CE3
006000 DFRFG1-FAIL 013310 CDATA-BSY.-LOAD 015043 MONIT-CE4
006001 DFRFG1-SYNC 013311 CDATA-CHK-ERR 019500 FCODE-250
006100 MFAIL-STATUS 013312 CURVEC1-X< 0 019521 FCODE-471.B0
006101 MFAIL-I-RESET 013313 CURVEC1-X> XMAX 019522 FCODE-471.B1
006400 FCNT1-EQUAL 013314 CDATA-X0_CYCLE 019523 FCODE-471.B2
010000 BRK1-OUT 013551 CLUT-OPEN 019524 FCODE-471.B3
010001 BRK1-CINH 013552 CLUT-OL 019525 FCODE-471.B4
010002 BRK1-QSP 013651 PSAVE-M-HI 019526 FCODE-471.B5
010003 BRK1-M-STORE 013652 PSAVE-M-LO 019527 FCODE-471.B6
010250 CW/CCW/Q-QSP 013653 PSAVE-ACT-HI 019528 FCODE-471.B7
010251 CW/CCW/Q-CW/CCW 013654 PSAVE-ACT-LO 019529 FCODE-471.B8
010500 AND1-OUT 013751 WELD-T-ERR 019530 FCODE-471.B9
010505 AND2-OUT 013752 WELD- ON 019531 FCODE-471.B10
010510 AND3-OUT 013753 WELD-DIR-ERR 019532 FCODE-471.B11
010515 AND4-OUT 013801 VMAS1-RFG-IN=OUT 019533 FCODE-471.B12
010520 AND5-OUT 013911 CONVPHPHD1-FAIL 019534 FCODE-471.B13
010550 OR1-OUT 013951 RFGPH1-RFG-I= 0 019535 FCODE-471.B14
010555 OR2-OUT 014050 STORE1-TP-INH 019536 FCODE-471.B15
010560 OR3-OUT 014055 STORE2-TP-INH 019537 FCODE-471.B16
010565 OR4-OUT 015000 DCTRL-TRIP 019538 FCODE-471.B17
010570 OR5-OUT 015001 DCTRL-MESS 019539 FCODE-471.B18
010600 NOT1-OUT 015002 DCTRL-WARN 019540 FCODE-471.B19
010605 NOT2-OUT 015003 DCTRL-FAIL 019541 FCODE-471.B20
010610 NOT3-OUT 015010 MONIT-LU 019542 FCODE-471.B21
010615 NOT4-OUT 015011 MONIT-OU 019543 FCODE-471.B22
