Lenze EVS9323-EK User Manual

Configuration
7-325

SHB9300CRV EN 2.0
Selection list 2, digital output signals (
P
) - continued -
019544 FCODE-471.B23 020119 CAN-IN1.B18 020304 CAN-IN3.B3 025110 AIF-IN.B9
019545 FCODE-471.B24 020120 CAN-IN1.B19 020305 CAN-IN3.B4 025111 AIF-IN.B10
019546 FCODE-471.B25 020121 CAN-IN1.B20 020306 CAN-IN3.B5 025112 AIF-IN.B11
019547 FCODE-471.B26 020122 CAN-IN1.B21 020307 CAN-IN3.B6 025113 AIF-IN.B12
019548 FCODE-471.B27 020123 CAN-IN1.B22 020308 CAN-IN3.B7 025114 AIF-IN.B13
019549 FCODE-471.B28 020124 CAN-IN1.B23 020309 CAN-IN3.B8 025115 AIF-IN.B14
019550 FCODE-471.B29 020125 CAN-IN1.B24 020310 CAN-IN3.B9 025116 AIF-IN.B15
019551 FCODE-471.B30 020126 CAN-IN1.B25 020311 CAN-IN3.B10 025117 AIF-IN.B16
019552 FCODE-471.B31 020127 CAN-IN1.B26 020312 CAN-IN3.B11 025118 AIF-IN.B17
019751 FCODE-135.B0 020128 CAN-IN1.B27 020313 CAN-IN3.B12 025119 AIF-IN.B18
019752 FCODE-135.B1 020129 CAN-IN1.B28 020314 CAN-IN3.B13 025120 AIF-IN.B19
019753 FCODE-135.B2 020130 CAN-IN1.B29 020315 CAN-IN3.B14 025121 AIF-IN.B20
019755 FCODE-135.B4 020131 CAN-IN1.B30 020316 CAN-IN3.B15 025122 AIF-IN.B21
019756 FCODE-135.B5 020132 CAN-IN1.B31 020317 CAN-IN3.B16 025123 AIF-IN.B22
019757 FCODE-135.B6 020201 CAN-IN2.B0 020318 CAN-IN3.B17 025124 AIF-IN.B23
019758 FCODE-135.B7 020202 CAN-IN2.B1 020319 CAN-IN3.B18 025125 AIF-IN.B24
019763 FCODE-135.B12 020203 CAN-IN2.B2 020320 CAN-IN3.B19 025126 AIF-IN.B25
019764 FCODE-135.B13 020204 CAN-IN2.B3 020321 CAN-IN3.B20 025127 AIF-IN.B26
019765 FCODE-135.B14 020205 CAN-IN2.B4 020322 CAN-IN3.B21 025128 AIF-IN.B27
019766 FCODE-135.B15 020206 CAN-IN2.B5 020323 CAN-IN3.B22 025129 AIF-IN.B28
020001 CAN-CTRL.B0 020207 CAN-IN2.B6 020324 CAN-IN3.B23 025130 AIF-IN.B29
020002 CAN-CTRL.B1 020208 CAN-IN2.B7 020325 CAN-IN3.B24 025131 AIF-IN.B30
020003 CAN-CTRL.B2 020209 CAN-IN2.B8 020326 CAN-IN3.B25 025132 AIF-IN.B31
020005 CAN-CTRL.B4 020210 CAN-IN2.B9 020327 CAN-IN3.B26
020006 CAN-CTRL.B5 020211 CAN-IN2.B10 020328 CAN-IN3.B27
020007 CAN-CTRL.B6 020212 CAN.IN2.B11 020329 CAN-IN3.B28
020008 CAN-CTRL.B7 020213 CAN-IN2.B12 020330 CAN-IN3.B29
020013 CAN-CTRL.B12 020214 CAN-IN2.B13 020331 CAN-IN3.B30
020014 CAN-CTRL.B13 020215 CAN-IN2.B14 020332 CAN-IN3.B31
020015 CAN-CTRL.B14 020216 CAN-IN2.B15 025001 AIF-CTRL.B0
020016 CAN-CTRL.B15 020217 CAN-IN2.B16 025002 AIF-CTRL.B1
020101 CAN-IN1.B0 020218 CAN-IN2.B17 025003 AIF-CTRL.B2
020102 CAN-IN1.B1 020219 CAN-IN2.B18 025005 AIF-CTRL.B4
020103 CAN-IN1.B2 020220 CAN-IN2.B19 025006 AIF-CTRL.B5
020104 CAN-IN1.B3 020221 CAN-IN2.B20 025007 AIF-CTRL.B6
020105 CAN-IN1.B4 020222 CAN-IN2.B21 025008 AIF-CTRL.B7
020106 CAN-IN1.B5 020223 CAN-IN2.B22 025013 AIF-CTRL.B12
020107 CAN-IN1.B6 020224 CAN-IN2.B23 025014 AIF-CTRL.B13
020108 CAN-IN1.B7 020225 CAN-IN2.B24 025015 AIF-CTRL.B14
020109 CAN-IN1.B8 020226 CAN-IN2.B25 025016 AIF-CTRL.B15
020110 CAN-IN1.B9 020227 CAN-IN2.B26 025101 AIF-IN.B0
020111 CAN-IN1.B10 020228 CAN-IN2.B27 025102 AIF-IN.B1
020112 CAN-IN1.B11 020229 CAN-IN2.B28 025103 AIF-IN.B2
020113 CAN-IN1.B12 020230 CAN-IN2.B29 025104 AIF-IN.B3
020114 CAN-IN1.B13 020231 CAN-IN2.B30 025105 AIF-IN.B4
020115 CAN-IN1.B14 020232 CAN-IN2.B31 025106 AIF-IN.B5
020116 CAN-IN1.B15 020301 CAN-IN3.B0 025107 AIF-IN.B6
020117 CAN-IN1.B16 020302 CAN-IN3.B1 025108 AIF-IN.B7
020118 CAN-IN1.B17 020303 CAN-IN3.B2 025109 AIF-IN.B8
