Lenze EVS9323-EK User Manual

Commissioning
5-7
 SHB9300CRV EN 2.0
5.5.3 Enter machine parameters
4
3
2
1
5
6
7
Field Drive Function
1 Enter numerator for the gear ratio of the cam drive
2
C
a
m
d
r
i
v
e
Enter denominator for the gear ratio of the cam drive
3
C
a
m
d
r
i
v
e
Output feed
4 Enter upper speed limit for the cam drive
5 Enter numerator for the gear ratio of the cam drive
6
Master drive
Enter denomintor for the gear ratio of the master drive
7
M
a
s
t
e
r
d
r
i
v
e
Output feed
Note!
For a detailed example with terminology definition see chapter 5.10.
