Lenze EVS9323-ES

Appendix
11-24

BA9300SU EN 2.1
Code ImportantPossible settingsLCDCode Important
ChoiceLenze
LCD
C0126
021,7 &(
3 0Trip
2 Warning
3Off
Conf. CE0
Configuration communication error monitoring
with automation interface CE0
C0130
DES 7J g
NSET actual Ti times
C0134
5)* EID5DE
0 0/1 NSET RFG characteristic
Ramp characteristic for main setpoint
0: linear
1: S-shaped
C0135
&O1S5OM UO5'
0 0 {1} 65535 Control word
Controller control word for LECOM-A/B/LI or
operating module.
C0136
1
2
3
&75/:25'
&75/:25'
&75/:25'
g
Control word C135
Control word in DCTRL
Control word in CAN-IN1
Control word in AIF-IN
C0141
)&2'( RFSTDM
0.00 -199.99 {0.01 %} 199.99 Main setpoint
Used for relative analog signals. Used as main
setpoint in configurations C0005 = xxx1
C0142
6SD5S OPSJO1R
1 0{1} 1Start conditions are executed:
• after mains connection
• after message (t > 0.5s)
• after trip
0Startlock
1 Autostart
C0150
6SDS8R UO5' g
0 {1} 65535 Status word when networked with automation
interfaces
• Binary interpretation indicates the bit states
C0151
)'2 ': g
Bit00 {01} Bit 31 FDO signals (DW)
Display (hex.) of free digital outputs
• Binary interpretation indicates the bit states
C0155
67$786 :25'  g
Bit00 {01} Bit 15 Status word 2
Display (hex.) of free digital outputs
• Binary interpretation indicates the bit states
[C0156]
1
2
3
4
5
6
7
67$7%
67$7%
67$7%
67$7%
67$7%
67$7%
67$7%
2000
5002
5003
5050
10650
505
500
→ Selection list 2
DCTRL-PAR*1-O
MCTRL-IMAX
MCTRL- MMAX
NSET-RFG I=O
CMP1-OUT
DCTRL-CW/CCW
DCTRL-RDY
STAT# (status word)
Configuration of the free bits of the status word
C0157
& g
01STAT# (status word)
Display of C0156
C0161
$ES S5JP g
All fault indications
(see chapter 9.3)
Fault message TRIP
momentary fault indiations (as under C0168/1)
C0167
5FRFS GDJMNFN
0 0 No reset
1 Reset
History buffer reset
Clears the history buffer
C0168
1
2
3
4
5
6
7
8
)DJM 1O DES
)DJM 1O OM'
)DJM 1O OM'
)DJM 1O OM'
)DJM 1O OM'
)DJM 1O OM'
)DJM 1O OM'
)DJM 1O OM'
g
All fault indications
(see chapter 9.3)
History buffer number
• List of faults occurred
History buffer
Faults are
1: active
2: last
3: last but one
4: last but three
5: last but four
6: last but five
7: last but six
8: last but seven
