Torque characteriscs
The torque/speed characterisc for your motor/inverter combinaon can be
found on the Internet:
hp://www.lenze.com à Product Finder à M-n characteriscs
The following data apply to a mains voltage 3 x 400 V of the inverter.
m850-S120/S3960
M = 4 V
max
4 0
M = V
max
400
M = 36 V
max
0
M @ I = 2x I
max max 0
S1
r/min
Nm
0
2
4
6
8
10
12
14
16
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
m850-S120/M3960
0
5
10
15
20
25
30
35
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
M = 4 V
max
4 0
M = V
max
400
M = 36 V
max
0
M @ I = 3x I
max max 0
M @ I = 2x I
max max 0
S1
r/min
Nm
Motor data
Torque characteriscs
146
