Lenze G7 Series - Page 43

Product code feedbacks
Example AS 1024 - 8V - K 2
Meaning Variant Product code
Product family Resolver RS
Resolver for safety funcon RV
Incremental encoder IG
Incremental encoder with commutaon signal IK
Singleturn absolute value encoder AS
Multum absolute value encoder AM
Number 2-pole resolver for servo motors 0
2-pole resolver for three-phase AC motors 1
Number of pole pairs for resolvers 2
3
4
...
Number of steps / increments per revoluon 20
32
128
512
1024
2048
...
Supply voltage 5V
8V
15V
24V
...
Interface or signal level Standard
TTL T
HTL (for incremental encoders) H
Hiperface (for absolute value encoders) H
EnDat E
sin/cos 1 Vss S
Digital D
For safety funcon
TTL U
HTL (for incremental encoders) K
Hiperface (for absolute value encoders) K
EnDat F
sin/cos 1 Vss V
Digital D
Safety integraon level (SIL) 1
2
3
4
Product informaon
Idencaon of the products
Product codes
