Posion of the output ange
Output ange on both sides "L+R".
L
R
Posion of the torque plate on the threaded pitch circle
Posion of the torque plate
L
R
Angle of the torque plate
g500-B45 ... B110
90°
270°
225°
135°
315°
R
180°
90°
270°
225°
45°
315°
L
0°
g500-B240 ... B1500
90°
270°
150°
210°
240°
60°
120°
300°
180°
R
90°
270°
330°
30°
240°
60°
120°
300°
0°
L
Product informaon
The modular system
Mounng posions
