The values given in the tables refer to the centre sha end force applicaon point and are
minimum values calculated according to the most unfavourable condions (force applicaon
angle, mounng posion, direcon of rotaon). The values were calculated with a load
capacity of c= 1.3 and an input speed of 1400 rpm.
In case of dierent operang condions, considerably higher forces can be
transmied. Please get in touch with your Lenze representave
A hollow sha with shrink disc (SAR/SBR/SCR/SDR/SAK/SCK) requires a check by
Lenze.
Max. radial force, gearbox with hollow sha (H□□)
Getriebe
Output speed n
2
[rpm]
1000 630 400 250 160 100 63 40 25 16
Max. radial force F
rad,max
[N]
g500-B45 900 1200 2200 2500 2800 3000 3000 3000 3000 3000
g500-B110 1000 2200 2600 3000 3300 3600 3600 3600 3600 3600
g500-B240 1500 2300 3800 4500 5100 6200 7400 7800 7800 7800
g500-B450 3000 3800 4500 5200 5200 5500 7000 9000 9000 9000
g500-B600 3500 4000 4700 5400 5600 6000 8000 9400 9500 9500
g500-B820 4000 4200 5400 5800 6000 7000 9000 9800 10200 10200
g500-B1500 3700 5000 6000 7000 8000 9000 10500 13000 16000 16000
g500-B2700 4400 5700 7000 8200 9400 10600 12200 15000 18000 21900
g500-B4300 5000 6600 8000 9000 10500 12000 15500 21000 27900 35100
Max. radial force, gearbox with solid sha, without ange (V□R)
Getriebe
Output speed n
2
[rpm]
1000 630 400 250 160 100 63 40 25 16
Max. radial force F
rad,max
[N]
g500-B45 900 1200 1800 2100 2400 2800 3000 3000 3000 3000
g500-B110 1000 1800 2100 2500 2700 3000 3000 3000 3000 3000
g500-B240 1500 2400 3000 3600 4500 5000 6000 6500 6500 6500
g500-B450 2000 2800 3600 3900 4300 5000 6000 7600 7800 7800
g500-B600 2500 3200 4000 4700 5400 6700 8300 9000 9000 9000
g500-B820 5200 6000 8200 9800 11000 11000 11000 11000 11000 11000
g500-B1500 6300 8200 10000 11500 13000 16000 16000 16000 16000 16000
g500-B2700 6600 8500 10400 12000 14000 16500 20100 22700 25500 27500
g500-B4300 7300 9500 11600 13300 14900 17300 20800 25700 32200 40000
Max. radial force, gearbox with solid sha and ange (V□K)
Getriebe
Output speed n
2
[rpm]
1000 630 400 250 160 100 63 40 25 16
Max. radial force F
rad,max
[N]
g500-B45 900 1200 1800 2100 2400 2800 3000 3000 3000 3000
g500-B110 1000 1800 2100 2500 2700 3000 3000 3000 3000 3000
g500-B240 2400 3600 5200 6000 6500 6500 6500 6500 6500 6500
g500-B450 3000 4000 4700 5100 5600 6400 7700 7800 7800 7800
g500-B600 3400 4100 5000 5300 6000 7300 9000 9000 9000 9000
g500-B820 6000 7000 8900 10200 11000 11000 11000 11000 11000 11000
g500-B1500 7000 9000 11000 12000 13000 15000 16000 16000 16000 16000
g500-B2700 8400 10900 13300 14400 15800 17700 20100 22700 25500 27500
g500-B4300 9200 11700 14300 15800 17800 20800 24800 29500 35100 40000
Technical data
Radial forces and axial forces
63
