Lenze GSS Series User Manual

Mechanical installation
Mounting
Breather position, oil filling screw and drain plug
5
46
Lenze • BA 12.0023 • 9.0
Helical-bevel gearbox GKS 05 ... 14-3
A B C
1
2
* GKS05...07
* GKS09...14
1
2
*
GKS09...14
***
GKS09...14
1
2
* GKS05...07
* GKS09...14
GKS09...14
GKS05...07
D E F
GKS09...14
1
2
GKS09...14
GKS05...07
GKS05...07
GKS05...07
GKS09...14
**
GKS09...14
GKS05...07
**
GT-GNG-GKS-3-001_A-F.iso/dms
A...F Mounting positions Oil drain plug
* Onbothsides
Oilcontrolplug
** On the opposite side Pos. 1 Standard
*** GKS05...07 with torque plate on the foot
in position 4
Pos. 2 only for: GKS05-3M  090C
GKS05-3M  100C
GKS06-3M  112C
GKS07-3M  160C
Ventilation / oil filler plug
