Lenze GSS Series User Manual

Maintenance
Maintenance operations
Lubricant quantity
8
63
Lenze • BA 12.0023 • 9.0
Pre-stage GST-3; GKS-4; GSS-3
Mounting
position
A B C D E F
GT-GNG-GST/GFL-010.iso/dms
GST05 0.12
0.15 W≥1C
0.3
0.35 W≥1C
0.15 0.3
0.35 N≥1B
0.4 W≥1C
0.2 0.2
GST06 0.15 0.4 0.35 0.3
0.4 W≥1C
0.3 0.3
GST07 0.3 0.7 0.5 0.55
0.65 M≥90
A ≥80
N ≥1D
0.4 0.4
GST09 0.6 1.4 1.1 1.2 0.8 0.8
GST11 1.5
2.0 M≥132
A≥112
N≥1G
W≥1G
2.5
2.9 M≥132
A≥112
N≥1G
W≥1G
2.1 1.7
2.4 M≥132
A ≥112
N ≥1G
W≥1G
1.7 1.7
GST14 2.7
4.0 M≥132
A≥112
N≥1G
4.6
5.2 M≥132
A≥112
N≥1G
W≥1G
4.3 3.2
4.1 M≥132
A≥112
N≥1G
W≥1G
3 3
Pre-stage shaft-mounted helical gearbox GFL-3
GFL05 0.2 0.2 0.15 0.3
0.35 N≥1B 0.4
W≥1C
0.12
0.15 W≥1C
0.3
0.35 W≥1C
GFL06 0.3 0.3 0.35 0.3
0.4 W≥1C
0.15 0.4
GFL07 0.4 0.4 0.5 0.55
0.65 M≥90
A ≥80
N ≥1D
0.3 0.7
GFL09 0.8 0.8 1.1 1.2 0.6 1.4
GFL11 1.7 1.7 2.1 1.7
2.4 M≥132
A ≥112
N ≥1G
W≥1G
1.5
2.0 M≥132
A≥112
N≥1G
W≥1G
2.5
2.9 M≥132
A≥112
N≥1G
W≥1G
GFL14 3.0 3.0 4.3 3.2
4.1 M≥132
A≥112
N≥1G
W≥1G
2.7
4.0 M≥132
A≥112
N≥1G
W≥1G
4.6
5.2 M≥132
A≥112
N≥1G
Tab. 9 Amount of lubricant in litres

Drive 90...132 Motor size
A, M, N, W Drive-end version 1A ...2K Drive size
