Lenze GSS Series User Manual

Maintenance
Maintenance operations
Lubricant quantity
8
64
Lenze • BA 12.0023 • 9.0
Helical gearbox GST-1VA /VB(foot housing)
Mounting
position
A B C D E F
GST04
0.1 0.37 0.2 0.3
0.35 W≥1C
0.25 0.25
GST05
0.2 0.6 0.35 0.5
0.6 M≥90
A ≥80
N≥1D
0.35 0.35
GST06
0.4 1.2 0.65 0.85
1W≥1E
0.7 0.7
GST07
0.7
1.3 M≥132
A≥112
N≥1G
W≥1G
2.3
2.7 M≥132
A≥112
N≥1G
W≥1G
1.3 1.5
2.2 M≥132
A≥112
N≥1G
W≥1G
1.5 1.5
GST09
1.2
2.5 M≥132
A≥112
N≥1G
W≥1G
4.1
4.8 M≥132
A≥112
N≥1G
W≥1G
2.8 2.7
3.7 M≥132
A≥112
N≥1G
W≥1G
2.5 2.5
Helical gearbox GST-1 VC(flange housing)
Mounting
position
A B C D E F
GST04
0.1 0.3 0.15 0.3
0.35 W≥1C
0.2 0.2
GST05
0.2 0.5 0.2 0.45
0.55 M≥90
A ≥80
N≥1D
0.3 0.3
GST06
0.4 1 0.45 0.85
1W≥1E
0.6 0.6
GST07
0.8
1.5 M≥132
A≥112
N≥1G
W≥1G
1.6
2.0 M≥132
A≥112
N≥1G
W≥1G
0.85 1.6
2.3 M≥132
A≥112
N≥1G
W≥1G
1.3 1.3
GST09
1.6
2.7 M≥132
A≥112
N≥1G
W≥1G
3.0
3.5 M≥132
A≥112
N≥1G
W≥1G
1.7 2.7
3.7 M≥132
A≥112
N≥1G
W≥1G
2.3 2.3
Tab. 10 Amount of lubricant in litres

Drive 90...132 Motor size
A, M, N, W Drive-end version 1A ...2K Drive size
