Address Designaon Default seng Category Data type Factor A M
0x282B:003
(P125.03)
Inverter diagnoscs: Keypad LCD status - (Read only) general U8 1 O -
0x282B:004
(P125.04)
Inverter diagnoscs: Acve drive mode - (Read only) general U8 1 O t
0x282B:005
(P125.05)
Inverter diagnoscs: Most recently used control reg-
ister
- (Read only) general U32 1 OH -
0x282B:006
(P125.06)
Inverter diagnoscs: Most recently used setpoint
register
- (Read only) general U32 1 OH -
0x282B:007 Inverter diagnoscs: Default frequency setpoint x.x Hz (Read only) general I16 10 - -
0x282B:008 Inverter diagnoscs: Preset frequency setpoint x.x Hz (Read only) general I16 10 - -
0x282B:009 Inverter diagnoscs: Actual frequency setpoint x.x Hz (Read only) general I16 10 - -
0x282B:010 Inverter diagnoscs: Default PID setpoint x.xx PID unit (Read only) general I16 100 - -
0x282B:011 Inverter diagnoscs: Preset PID setpoint x.xx PID unit (Read only) general I16 100 - -
0x282B:012 Inverter diagnoscs: Default torque setpoint x.x % (Read only) general I16 10 - -
0x282B:013 Inverter diagnoscs: Preset torque setpoint x.x % (Read only) general I16 10 - -
0x2831 Inverter status word - (Read only) general U16 1 O t
0x2833 Inverter status word 2 - (Read only) general U16 1 O t
0x2838:001
(P203.01)
Start/stop conguraon: Start method Normal [0] general U8 1 PC -
0x2838:002
(P203.02)
Start/stop conguraon: Start at power-up O [0] general U8 1 P -
0x2838:003
(P203.03)
Start/stop conguraon: Stop method Standard ramp [1] general U8 1 P -
0x2839:002
(P760.02)
Fault conguraon: Restart delay 3.0 s general U16 10 P -
0x2839:003
(P760.03)
Fault conguraon: Number of restart aempts 5 general U8 1 P -
0x2839:004
(P760.04)
Fault conguraon: Trouble counter reset me 40.0 s general U16 10 P -
0x2839:005
(P760.05)
Fault conguraon: Trouble counter - (Read only) general U8 1 - -
0x2839:006 Fault conguraon: Fault handling in case of state
change
Reset fault [0] general U8 1 P -
0x283A
(P304.00)
Limitaon of rotaon Both rotaonal direcons
[1]
general U8 1 P -
0x2857:001 CANopen monitoring: RPDO1-Timeout Fault [3] CANopen U8 1 P -
0x2857:002 CANopen monitoring: RPDO2-Timeout Fault [3] CANopen U8 1 P -
0x2857:003 CANopen monitoring: RPDO3-Timeout Fault [3] CANopen U8 1 P -
0x2857:005 CANopen monitoring: Heartbeat-Timeout Consumer
1
Fault [3] CANopen U8 1 P -
0x2857:006 CANopen monitoring: Heartbeat-Timeout Consumer
2
Fault [3] CANopen U8 1 P -
0x2857:007 CANopen monitoring: Heartbeat-Timeout Consumer
3
Fault [3] CANopen U8 1 P -
0x2857:008 CANopen monitoring: Heartbeat-Timeout Consumer
4
Fault [3] CANopen U8 1 P -
0x2857:010 CANopen monitoring: "Bus-o" state change Trouble [2] CANopen U8 1 P -
0x2857:011 CANopen monitoring: Warning Warning [1] CANopen U8 1 P -
0x2858:001
(P515.01)
Modbus monitoring: Response to me-out Fault [3] Modbus RTU U8 1 P -
0x2858:002
(P515.02)
Modbus monitoring: Time-out me 2.0 s Modbus RTU U16 10 P -
0x2860:001
(P201.01)
Frequency control: Default setpoint source Analog input 1 [2] general U8 1 P -
0x2860:002
(P201.02)
PID control: Default setpoint source Keypad [1] general U8 1 P -
0x2860:003
(P201.03)
Torque control: Default setpoint source Analog input 1 [2] general U8 1 P -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
