Address Designaon Default seng Category Data type Factor A M
0x2C01:010 Motor parameters: Motor name MCTRL STRING[25] 1 P -
0x2C02:001
(P351.01)
Motor parameter (ASM): Rotor resistance 8.8944 Ω * MCTRL U32 10000 P -
0x2C02:002
(P351.02)
Motor parameter (ASM): Mutual inductance 381.9 mH * MCTRL U32 10 P -
0x2C02:003
(P351.03)
Motor parameter (ASM): Magnesing current 0.96 A * MCTRL U16 100 P -
0x2C02:004
(P351.04)
Slip frequency x.x Hz (Read only) general U16 10 - -
0x2C03:001
(P352.01)
Back EMF constant 41.8 V/1000rpm MCTRL U32 10 P -
0x2C11:001 High speed range: Lower limit 30 % general U16 1 P -
0x2C11:002 High speed range: Tracking controller gain 200 % general U16 1 P -
0x2C11:003 High speed range: Tracking controller reset me 6.00 ms general U16 100 P -
0x2C11:004 High speed range: Tracking controller decouple me 200.0 ms general U16 10 P -
0x2C11:006 High speed range: Stall monitoring limit 50 % general U16 1 P -
0x2C12:001 SM low speed range: Acceleraon current 70 % MCTRL U16 1 P -
0x2C12:002 SM low speed range: Standsll current 30 % MCTRL U16 1 P -
0x2C49:001
(P711.01)
Posion counter: Signal source Disbled [0] general U8 1 P -
0x2C49:002
(P711.02)
Posion counter: Reset mode Reset by rising edge [0] general U8 1 P -
0x2C49:003
(P711.03)
Posion counter: Actual posion - (Read only) general U32 1 H t
0x2C60 PPI monitoring: Reacon Fault [3] general U8 1 P -
0x2C63:001 PPI without movement: Execuon Aer each enable [2] general U8 1 PC -
0x2D40:002 Device ulisaon (i*t): Warning threshold 95 % general U16 1 P -
0x2D40:004
(P135.04)
Device ulisaon (i*t) x % (Read only) general U16 1 O t
0x2D40:005
(P135.05)
Device ulisaon (i*t): Error response Fault [3] general U8 1 P -
0x2D44:001
(P350.01)
Overspeed monitoring: Threshold 8000 rpm general U16 1 P -
0x2D44:002
(P350.02)
Overspeed monitoring: Response Fault [3] general U8 1 P -
0x2D45:001
(P310.01)
Motor phase failure detecon: Response No response [0] general U8 1 P -
0x2D45:002
(P310.02)
Motor phase failure detecon: Current threshold 5.0 % general U8 10 P -
0x2D45:003
(P310.03)
Motor phase failure detecon: Voltage threshold 10.0 V general U16 10 P -
0x2D46:001
(P353.01)
Overcurrent monitoring: Threshold 6.8 A * general U16 10 P -
0x2D46:002
(P353.02)
Overcurrent monitoring: Response Fault [3] general U8 1 P -
0x2D4B:001
(P308.01)
Motor overload monitoring (i²*t): Maximum ulisa-
on [60 s]
150 % general U16 1 P -
0x2D4B:002
(P308.02)
Motor overload monitoring (i²*t): Speed compensa-
on
On [0] general U8 1 P -
0x2D4B:003
(P308.03)
Motor overload monitoring (i²*t): Response Fault [3] general U8 1 P -
0x2D4B:005 Motor overload monitoring (i²*t): Thermal load - (Read only) general U16 1 - -
0x2D4F
(P123.00)
Motor ulisaon (i²*t) x % (Read only) general U16 1 O t
0x2D66:001
(P721.01)
Mains failure control: Enable funcon Disabled [0] general U8 1 P -
0x2D66:002
(P721.02)
Mains failure control: DC-bus acvaon level 0 % * general U8 1 P -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
475
