Lenze I51AE175B - Page 478

Address Designaon Default seng Category Data type Factor A M
0x4005
(P412.00)
Frequency threshold 0.0 Hz general U16 10 P -
0x4006:001
(P710.01)
Load loss detecon: Threshold 0.0 % general U16 10 P -
0x4006:002
(P710.02)
Load loss detecon: Deceleraon 0.0 s general U16 10 P -
0x4008:001
(P590.01)
Process input words: NetWordIN1 0x0000 general U16 1 HK r
0x4008:002
(P590.02)
Process input words: NetWordIN2 0x0000 general U16 1 HK r
0x4008:003
(P590.03)
Process input words: NetWordIN3 0.0 % general U16 10 K r
0x4008:004
(P590.04)
Process input words: NetWordIN4 0.0 % general U16 10 K r
0x4008:005
(P550.05)
Process input words: NetWordIN5 0.0 % general I16 10 OK r
0x4009:001 MOP values saved: Frequency x.x Hz (Read only) general U16 10 - t
0x4009:002 MOP values saved: PID value x.xx PID unit (Read only) general I16 100 - t
0x4009:003 MOP values saved: Torque x.x % (Read only) general U16 10 - t
0x4009:004 MOP values saved: Frequency setpoint x.x Hz (Read only) general I16 10 - -
0x4009:005 MOP values saved: PID setpoint x.xx PID unit (Read only) general I16 100 - -
0x4009:006 MOP values saved: Torque setpoint x.x % (Read only) general I16 10 - -
0x400A:001
(P591.01)
Process output words: NetWordOUT1 - (Read only) general U16 1 H t
0x400A:002
(P591.02)
Process output words: NetWordOUT2 - (Read only) general U16 1 - t
0x400B:001
(P592.01)
Process input data: AC Drive control word 0x0000 general U16 1 OH
K
r
0x400B:002
(P592.02)
Process input data: LECOM control word 0x0000 general U16 1 OH
K
r
0x400B:003
(P592.03)
Process input data: Network setpoint frequency
(0.1)
0.0 Hz general U16 10 OK r
0x400B:004
(P592.04)
Process input data: Network setpoint speed 0 rpm general U16 1 OK r
0x400B:005
(P592.05)
Process input data: Network setpoint frequency
(0.01)
0.00 Hz general U16 100 OK r
0x400B:006
(P592.06)
Process input data: Velocity mode setpoint 0.0 Hz general I16 10 OK r
0x400B:007
(P592.07)
Process input data: PID setpoint 0.00 PID unit general I16 100 OK r
0x400B:008
(P592.08)
Process input data: Torque mode setpoint 0 Nm general I16 1 OK r
0x400B:009
(P592.09)
Process input data: Torque scaling 0 general I8 1 OK -
0x400B:011
(P592.11)
Process input data: PID feedback 0.00 PID unit general I16 100 OK r
0x400B:012
(P592.12)
Process input data: Network setpoint frequency
[0.02Hz]
0 Hz general I16 50 K r
0x400B:013
(P592.13)
Process input data: Network frequency setpoint
[+/-16384]
0 general I16 1 O r
0x400C:001
(P593.01)
Process output data: AC Drive status word - (Read only) general U16 1 - t
0x400C:002
(P593.02)
Process output data: LECOM status word - (Read only) general U16 1 - t
0x400C:003
(P593.03)
Process output data: Frequency (0.1) x.x Hz (Read only) general U16 10 - t
0x400C:004
(P593.04)
Process output data: Motor speed x rpm (Read only) general U16 1 - t
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
478
