Address Designaon Default seng Category Data type Factor A M
0x400C:005
(P593.05)
Process output data: Drive status - (Read only) general U16 1 - t
0x400C:006
(P593.06)
Process output data: Frequency (0.01) x.xx Hz (Read only) general U16 100 - t
0x400C:007
(P593.07)
Process output data: Torque scaled - (Read only) general I16 1 - t
0x400C:008
(P593.08)
Process output data: Frequency [0.02 Hz] Hz (Read only) general I16 50 - t
0x400C:009
(P593.09)
Process output data: Frequency [+/-16384] - (Read only) general I16 1 O t
0x400D
(P101.00)
Scaled actual value x Units (Read only) general I16 1 O t
0x400E:001
(P505.01)
NetWordIN1 funcon: Bit 0 Not acve [0] general U8 1 PC -
0x400E:002
(P505.02)
NetWordIN1 funcon: Bit 1 Not acve [0] general U8 1 PC -
0x400E:003
(P505.03)
NetWordIN1 funcon: Bit 2 Acvate quick stop [3] general U8 1 PC -
0x400E:004
(P505.04)
NetWordIN1 funcon: Bit 3 Not acve [0] general U8 1 PC -
0x400E:005
(P505.05)
NetWordIN1 funcon: Bit 4 Run forward (CW) [8] general U8 1 PC -
0x400E:006
(P505.06)
NetWordIN1 funcon: Bit 5 Acvate preset (bit 0)
[18]
general U8 1 PC -
0x400E:007
(P505.07)
NetWordIN1 funcon: Bit 6 Acvate preset (bit 1)
[19]
general U8 1 PC -
0x400E:008
(P505.08)
NetWordIN1 funcon: Bit 7 Reset error [4] general U8 1 PC -
0x400E:009
(P505.09)
NetWordIN1 funcon: Bit 8 Not acve [0] general U8 1 PC -
0x400E:010
(P505.10)
NetWordIN1 funcon: Bit 9 Acvate DC braking [5] general U8 1 PC -
0x400E:011
(P505.11)
NetWordIN1 funcon: Bit 10 Not acve [0] general U8 1 PC -
0x400E:012
(P505.12)
NetWordIN1 funcon: Bit 11 Not acve [0] general U8 1 PC -
0x400E:013
(P505.13)
NetWordIN1 funcon: Bit 12 Reverse rotaonal direc-
on [13]
general U8 1 PC -
0x400E:014
(P505.14)
NetWordIN1 funcon: Bit 13 Not acve [0] general U8 1 PC -
0x400E:015
(P505.15)
NetWordIN1 funcon: Bit 14 Not acve [0] general U8 1 PC -
0x400E:016
(P505.16)
NetWordIN1 funcon: Bit 15 Not acve [0] general U8 1 PC -
0x4016:003 Digital output 1: Cutout delay 0.000 s general U16 1000 P -
0x4016:004 Digital output 1: Switch-on delay 0.000 s general U16 1000 P -
0x4016:005 Digital output 1: Terminal state - (Read only) general U8 1 - -
0x4016:006 Digital output 1: Trigger signal state - (Read only) general U8 1 - -
0x4018:003 Relay: Switch-o delay 0.000 s general U16 1000 P -
0x4018:004 Relay: Switch-on delay 0.000 s general U16 1000 P -
0x4018:005 Relay: Relay state - (Read only) general U8 1 - -
0x4018:006 Relay: Trigger signal state - (Read only) general U8 1 - -
0x4018:007 Relay: Switching cycles - (Read only) general U32 1 - -
0x401F:001
(P121.01)
Current setpoint x.xx PID unit (Read only) general I16 100 O t
0x401F:002
(P121.02)
Current process variable x.xx PID unit (Read only) general I16 100 O t
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
