Address Designaon Default seng Category Data type Factor A M
0x401F:003
(P121.03)
Status - (Read only) general U8 1 O t
0x401F:004 PID control value x.x Hz (Read only) general I16 10 - -
0x401F:005 PID Feedforward value x.x Hz (Read only) general I16 10 - -
0x401F:006 PID output value x.x Hz (Read only) general I16 10 - -
0x401F:007 PID error value x.xx PID unit (Read only) general I32 100 - -
0x4020:001
(P600.01)
Process controller setup (PID): Operang mode Inhibited [0] general U8 1 P -
0x4020:002
(P600.02)
Process controller setup (PID): PID process variable Analog input 1 [1] general U8 1 P -
0x4020:003
(P600.03)
Process controller setup (PID): Closed-loop control-
led speed range
100 % general U16 1 P rt
0x4020:004
(P600.04)
Process controller setup (PID): Speed feedforward
control source
Without speed addion
[0]
general U8 1 P -
0x4020:005
(P600.05)
Process controller setup (PID): Min speed limit -100.0 % general I16 10 P -
0x4020:006
(P600.06)
Process controller setup (PID): Max speed limit 100.0 % general I16 10 P -
0x4021:001
(P606.01)
PID speed operaon: Acceleraon me 1.0 s general U16 10 P -
0x4021:002
(P606.02)
PID speed operaon: Deceleraon me 1.0 s general U16 10 P -
0x4022:001
(P451.01)
PID setpoint presets: Preset 1 0.00 PID unit general I16 100 P -
0x4022:002
(P451.02)
PID setpoint presets: Preset 2 0.00 PID unit general I16 100 P -
0x4022:003
(P451.03)
PID setpoint presets: Preset 3 0.00 PID unit general I16 100 P -
0x4022:004
(P451.04)
PID setpoint presets: Preset 4 0.00 PID unit general I16 100 P -
0x4022:005
(P451.05)
PID setpoint presets: Preset 5 0.00 PID unit general I16 100 P -
0x4022:006
(P451.06)
PID setpoint presets: Preset 6 0.00 PID unit general I16 100 P -
0x4022:007
(P451.07)
PID setpoint presets: Preset 7 0.00 PID unit general I16 100 P -
0x4022:008
(P451.08)
PID setpoint presets: Preset 8 0.00 PID unit general I16 100 P -
0x4023:001
(P610.01)
PID sleep mode: Acvaon Disabled [0] general U8 1 P -
0x4023:002
(P610.02)
PID sleep mode: Stop method Coasng [0] general U8 1 P -
0x4023:003
(P610.03)
PID sleep mode: Frequency threshold 0.0 Hz general U16 10 P -
0x4023:004
(P610.04)
PID sleep mode: Feedback threshold 0.00 PID unit general I16 100 P -
0x4023:005
(P610.05)
PID sleep mode: Delay me 0.0 s general U16 10 P -
0x4023:006
(P610.06)
PID sleep mode: Recovery Setpoint > threshold OR
system deviaon > band-
width [0]
general U8 1 P -
0x4023:007
(P610.07)
PID sleep mode: Bandwidth 0.00 PID unit general U16 100 P -
0x4023:008
(P610.08)
PID sleep mode: Recovery threshold 0.00 PID unit general I16 100 P -
0x4024:001
(P615.01)
Automac rinsing: Rinsing in idle state Inhibited [0] general U8 1 P -
0x4024:002
(P615.02)
Automac rinsing: Rinse interval 30.0 min general U16 10 P -
* Default seng depending on the size. Firmware version 05.00.00.00
