Lenze I51AE175B

Address Designaon Default seng Category Data type Factor A M
0x402C:009 Sequencer segment 7: Reserved 0 general U32 1 P -
0x402D:001
(P808.01)
Sequencer segment 8: Frequency setpoint 0.0 Hz general I16 10 P -
0x402D:002
(P808.02)
Sequencer segment 8: Acceleraon/deceleraon 5.0 s general U16 10 P -
0x402D:003
(P808.03)
Sequencer segment 8: Time 0.0 s general U32 10 P -
0x402D:004
(P808.04)
Sequencer segment 8: Digital outputs 0 general U8 1 P -
0x402D:005
(P808.05)
Sequencer segment 8: Analog outputs 0.00 VDC general U16 100 P -
0x402D:006
(P808.06)
Sequencer segment 8: PID setpoint 0.00 PID unit general I16 100 P -
0x402D:007
(P808.07)
Sequencer segment 8: Torque setpoint 100.0 % general I16 10 P -
0x402D:008 Sequencer segment 8: NetWordOUT2 0 general U16 1 P -
0x402D:009 Sequencer segment 8: Reserved 0 general U32 1 P -
0x402E:001
(P822.01)
End segment: Frequency setpoint 0.0 Hz general I16 10 P -
0x402E:002
(P822.02)
End segment: Acceleraon/deceleraon 5.0 s general U16 10 P -
0x402E:003
(P822.03)
End segment: Time 0.0 s general U32 10 P -
0x402E:004
(P822.04)
End segment: Digital outputs 0 general U8 1 P -
0x402E:005
(P822.05)
End segment: Analog outputs 0.00 VDC general U16 100 P -
0x402E:006
(P822.06)
End segment: PID setpoint 0.00 PID unit general I16 100 P -
0x402E:007
(P822.07)
End segment: Torque setpoint 100.0 % general I16 10 P -
0x402E:008 End segment: NetWordOUT2 0 general U16 1 P -
0x402E:009 End segment: Reserved 0 general U32 1 P -
0x402F
(P824.00)
End of sequence mode Keep running [0] general U8 1 P -
0x4030:001 ...
0x4030:016
(P830.01 ... 16)
Sequence 1: Step 1 ... Step 16 Skip step [0] general I8 1 P -
0x4031
(P831.00)
Number of cycles sequence 1 1 general U16 1 P -
0x4032:001 ...
0x4032:016
(P835.01 ... 16)
Sequence 2: Step 1 ... Step 16 Skip step [0] general I8 1 P -
0x4033
(P836.00)
Number of cycles sequence 2 1 general U16 1 P -
0x4034:001 ...
0x4034:016
(P840.01 ... 16)
Sequence 3: Step 1 ... Step 16 Skip step [0] general I8 1 P -
0x4035
(P841.00)
Number of cycles sequence 3 1 general U16 1 P -
0x4036:001 ...
0x4036:016
(P845.01 ... 16)
Sequence 4: Step 1 ... Step 16 Skip step [0] general I8 1 P -
0x4037
(P846.00)
Number of cycles sequence 4 1 general U16 1 P -
0x4038:001 ...
0x4038:016
(P850.01 ... 16)
Sequence 5: Step 1 ... Step 16 Skip step [0] general I8 1 P -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
