Address Designaon Default seng Category Data type Factor A M
0x4029:003
(P804.03)
Sequencer segment 4: Time 0.0 s general U32 10 P -
0x4029:004
(P804.04)
Sequencer segment 4: Digital outputs 0 general U8 1 P -
0x4029:005
(P804.05)
Sequencer segment 4: Analog outputs 0.00 VDC general U16 100 P -
0x4029:006
(P804.06)
Sequencer segment 4: PID setpoint 0.00 PID unit general I16 100 P -
0x4029:007
(P804.07)
Sequencer segment 4: Torque setpoint 100.0 % general I16 10 P -
0x4029:008 Sequencer segment 4: NetWordOUT2 0 general U16 1 P -
0x4029:009 Sequencer segment 4: Reserved 0 general U32 1 P -
0x402A:001
(P805.01)
Sequencer segment 5: Frequency setpoint 0.0 Hz general I16 10 P -
0x402A:002
(P805.02)
Sequencer segment 5: Acceleraon/deceleraon 5.0 s general U16 10 P -
0x402A:003
(P805.03)
Sequencer segment 5: Time 0.0 s general U32 10 P -
0x402A:004
(P805.04)
Sequencer segment 5: Digital outputs 0 general U8 1 P -
0x402A:005
(P805.05)
Sequencer segment 5: Analog outputs 0.00 VDC general U16 100 P -
0x402A:006
(P805.06)
Sequencer segment 5: PID setpoint 0.00 PID unit general I16 100 P -
0x402A:007
(P805.07)
Sequencer segment 5: Torque setpoint 100.0 % general I16 10 P -
0x402A:008 Sequencer segment 5: NetWordOUT2 0 general U16 1 P -
0x402A:009 Sequencer segment 5: Reserved 0 general U32 1 P -
0x402B:001
(P806.01)
Sequencer segment 6: Frequency setpoint 0.0 Hz general I16 10 P -
0x402B:002
(P806.02)
Sequencer segment 6: Acceleraon/deceleraon 5.0 s general U16 10 P -
0x402B:003
(P806.03)
Sequencer segment 6: Time 0.0 s general U32 10 P -
0x402B:004
(P806.04)
Sequencer segment 6: Digital outputs 0 general U8 1 P -
0x402B:005
(P806.05)
Sequencer segment 6: Analog outputs 0.00 VDC general U16 100 P -
0x402B:006
(P806.06)
Sequencer segment 6: PID setpoint 0.00 PID unit general I16 100 P -
0x402B:007
(P806.07)
Sequencer segment 6: Torque setpoint 100.0 % general I16 10 P -
0x402B:008 Sequencer segment 6: NetWordOUT2 0 general U16 1 P -
0x402B:009 Sequencer segment 6: Reserved 0 general U32 1 P -
0x402C:001
(P807.01)
Sequencer segment 7: Frequency setpoint 0.0 Hz general I16 10 P -
0x402C:002
(P807.02)
Sequencer segment 7: Acceleraon/deceleraon 5.0 s general U16 10 P -
0x402C:003
(P807.03)
Sequencer segment 7: Time 0.0 s general U32 10 P -
0x402C:004
(P807.04)
Sequencer segment 7: Digital outputs 0 general U8 1 P -
0x402C:005
(P807.05)
Sequencer segment 7: Analog outputs 0.00 VDC general U16 100 P -
0x402C:006
(P807.06)
Sequencer segment 7: PID setpoint 0.00 PID unit general I16 100 P -
0x402C:007
(P807.07)
Sequencer segment 7: Torque setpoint 100.0 % general I16 10 P -
0x402C:008 Sequencer segment 7: NetWordOUT2 0 general U16 1 P -
* Default seng depending on the size. Firmware version 05.00.00.00
Appendix
Parameter aribute list
