Display code Short designaon Default seng Seng range Address Category
└ P505.07 NetWordIN1.06 Setp: Preset b1 [19] Selecon list 0x400E:007 general
└ P505.08 NetWordIN1.07 Reset error [4] Selecon list 0x400E:008 general
└ P505.09 NetWordIN1.08 Not acve [0] Selecon list 0x400E:009 general
└ P505.10 NetWordIN1.09 DC braking [5] Selecon list 0x400E:010 general
└ P505.11 NetWordIN1.10 Not acve [0] Selecon list 0x400E:011 general
└ P505.12 NetWordIN1.11 Not acve [0] Selecon list 0x400E:012 general
└ P505.13 NetWordIN1.12 Reverse rot.dir. [13] Selecon list 0x400E:013 general
└ P505.14 NetWordIN1.13 Not acve [0] Selecon list 0x400E:014 general
└ P505.15 NetWordIN1.14 Not acve [0] Selecon list 0x400E:015 general
└ P505.16 NetWordIN1.15 Not acve [0] Selecon list 0x400E:016 general
P508.00 CANopen comm. No acon [0] Selecon list 0x2300 CANopen
P508.00 Modbus comm. No acon [0] Selecon list 0x2320 Modbus RTU
P509.00 CANopen switch - - (Read only) 0x2303 CANopen
P509.00 Modbus switch - - (Read only) 0x2323 Modbus RTU
P510.xx CANopen se.
└ P510.01 Node ID 1 1 ... 127 0x2301:001 CANopen
└ P510.02 Baud rate 500 kbps [5] Selecon list 0x2301:002 CANopen
└ P510.03 Slave/Master Slave [0] Selecon list 0x2301:003 CANopen
└ P510.04 Start rem. delay 3000 ms 0 ... 65535 ms 0x2301:004 CANopen
└ P510.05 SDO2 channel Not acve [0] Selecon list 0x2301:005 CANopen
└ P510.06 COB-ID Cong Base + node-ID [0] Selecon list 0x2301:006 CANopen
P510.xx Modbus se.
└ P510.01 Node ID 1 1 ... 247 0x2321:001 Modbus RTU
└ P510.02 Baud rate Automac [0] Selecon list 0x2321:002 Modbus RTU
└ P510.03 Data format Automac [0] Selecon list 0x2321:003 Modbus RTU
└ P510.04 Min. resp. me 0 ms 0 ... 1000 ms 0x2321:004 Modbus RTU
P511.xx CANopen diag.
└ P511.01 Acve node ID - - (Read only) 0x2302:001 CANopen
└ P511.02 Acve baud rate - - (Read only) 0x2302:002 CANopen
P511.xx Modbus diag.
└ P511.01 Acve node ID - - (Read only) 0x2322:001 Modbus RTU
└ P511.02 Acve baud rate - - (Read only) 0x2322:002 Modbus RTU
└ P511.03 Data format - - (Read only) 0x2322:003 Modbus RTU
P515.00 Time-out status - - (Read only) 0x2307 CANopen
P515.xx Modbus monit.
└ P515.01 Resp. Time-out Fault [3] Selecon list 0x2858:001 Modbus RTU
└ P515.02 Time-out me 2.0 s 0.0 ... 300.0 s 0x2858:002 Modbus RTU
P516.00 CANopen status - - (Read only) 0x2308 CANopen
P517.00 CAN contr.status - - (Read only) 0x2309 CANopen
P518.00 CAN errorcounter - - (Read only) 0x230B CANopen
P520.xx Cons. heartbeat
└ P520.00 Highest subindex - - (Read only) 0x1016:000 CANopen
└ P520.01 Cons. heartbeat1 0x00000000 0x00000000 ... 0x00FFFFFF 0x1016:001 CANopen
└ P520.02 Cons. heartbeat2 0x00000000 0x00000000 ... 0x00FFFFFF 0x1016:002 CANopen
└ P520.03 Cons. heartbeat3 0x00000000 0x00000000 ... 0x00FFFFFF 0x1016:003 CANopen
└ P520.04 Cons. heartbeat4 0x00000000 0x00000000 ... 0x00FFFFFF 0x1016:004 CANopen
P522.00 Prod. heartbeat 0 ms 0 ... 65535 ms 0x1017 CANopen
P530.xx Para. mapping
└ P530.01 ... 24 Parameter 1 ... Parameter
24
0x00000000 0x00000000 ... 0xFFFFFF00 0x232B:001 ...
0x232B:024
Modbus RTU
P531.xx Reg. assigned
└ P531.01 ... 24 Register 1 ... Register 24 - - (Read only) 0x232C:001 ...
0x232C:024
Modbus RTU
P532.00 Vericaoncode - - (Read only) 0x232D Modbus RTU
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
