Display code Short designaon Default seng Seng range Address Category
P540.xx RPDO1 cong.
└ P540.01 COB-ID 0x00000200 0x00000000 ... 0xFFFFFFFF 0x1400:001 CANopen
└ P540.02 Transm. type 255 0 ... 255 0x1400:002 CANopen
└ P540.05 Event mer 100 ms 0 ... 65535 ms 0x1400:005 CANopen
P541.xx RPDO2 cong.
└ P541.01 COB-ID 0x80000300 0x00000000 ... 0xFFFFFFFF 0x1401:001 CANopen
└ P541.02 Transm. type 255 0 ... 255 0x1401:002 CANopen
└ P541.05 Event mer 100 ms 0 ... 65535 ms 0x1401:005 CANopen
P542.xx RPDO3 cong.
└ P542.01 COB-ID 0x80000400 0x00000000 ... 0xFFFFFFFF 0x1402:001 CANopen
└ P542.02 Transm. type 255 0 ... 255 0x1402:002 CANopen
└ P542.05 Event mer 100 ms 0 ... 65535 ms 0x1402:005 CANopen
P550.xx TPDO1 cong.
└ P550.01 COB-ID 0x40000180 0x00000001 ... 0xFFFFFFFF 0x1800:001 CANopen
└ P550.02 Transm. type 255 0 ... 255 0x1800:002 CANopen
└ P550.03 Inhibit me 0.0 ms 0.0 ... 6553.5 ms 0x1800:003 CANopen
└ P550.05 Event mer 20 ms 0 ... 65535 ms 0x1800:005 CANopen
└ P550.05 NetWordIN5 0.0 % -100.0 ... 100.0 % 0x4008:005 general
P551.xx TPDO2 cong.
└ P551.01 COB-ID 0xC0000280 0x00000001 ... 0xFFFFFFFF 0x1801:001 CANopen
└ P551.02 Transm. type 255 0 ... 255 0x1801:002 CANopen
└ P551.03 Inhibit me 0.0 ms 0.0 ... 6553.5 ms 0x1801:003 CANopen
└ P551.05 Event mer 0 ms 0 ... 65535 ms 0x1801:005 CANopen
P552.xx TPDO3 cong.
└ P552.01 COB-ID 0xC0000380 0x00000001 ... 0xFFFFFFFF 0x1802:001 CANopen
└ P552.02 Transm. type 255 0 ... 255 0x1802:002 CANopen
└ P552.03 Inhibit me 0.0 ms 0.0 ... 6553.5 ms 0x1802:003 CANopen
└ P552.05 Event mer 0 ms 0 ... 65535 ms 0x1802:005 CANopen
P580.xx CAN stascs
└ P580.01 PDO1 received - - (Read only) 0x230A:001 CANopen
└ P580.02 PDO2 received - - (Read only) 0x230A:002 CANopen
└ P580.03 PDO3 received - - (Read only) 0x230A:003 CANopen
└ P580.05 PDO1 transmied - - (Read only) 0x230A:005 CANopen
└ P580.06 PDO2 transmied - - (Read only) 0x230A:006 CANopen
└ P580.07 PDO3 transmied - - (Read only) 0x230A:007 CANopen
└ P580.09 SDO1 counter - - (Read only) 0x230A:009 CANopen
└ P580.10 SDO2 counter - - (Read only) 0x230A:010 CANopen
P580.xx Modbus stasc
└ P580.01 Mess. received - - (Read only) 0x232A:001 Modbus RTU
└ P580.02 Val. mess. rec. - - (Read only) 0x232A:002 Modbus RTU
└ P580.03 Mess. w. exc. - - (Read only) 0x232A:003 Modbus RTU
└ P580.04 Mess. w. errors - - (Read only) 0x232A:004 Modbus RTU
└ P580.05 Messages sent - - (Read only) 0x232A:005 Modbus RTU
P583.xx Rx data diagn.
└ P583.01 Rx data oset 0 0 ... 240 0x232E:001 Modbus RTU
└ P583.02 Last RxD byte0 - - (Read only) 0x232E:002 Modbus RTU
└ P583.03 Last RxD byte1 - - (Read only) 0x232E:003 Modbus RTU
└ P583.04 Last RxD byte2 - - (Read only) 0x232E:004 Modbus RTU
└ P583.05 Last RxD byte3 - - (Read only) 0x232E:005 Modbus RTU
└ P583.06 Last RxD byte4 - - (Read only) 0x232E:006 Modbus RTU
└ P583.07 Letzt RxD-Byte5 - - (Read only) 0x232E:007 Modbus RTU
└ P583.08 Last RxD byte6 - - (Read only) 0x232E:008 Modbus RTU
└ P583.09 Last RxD byte7 - - (Read only) 0x232E:009 Modbus RTU
└ P583.10 Last RxD byte8 - - (Read only) 0x232E:010 Modbus RTU
* Default seng depending on the size. Firmware version 05.00.00.00
