Lenze i55 Series

Display code Short designaon Default seng Seng range Address Category
└ P500.01 Acve module ID - - (Read only) 0x231F:001 general
└ P500.02 Module ID conn. - - (Read only) 0x231F:002 general
P505.xx NetWordIN1 fct.
└ P505.01 NetWordIN1.00 Not acve [0] Selecon list 0x400E:001 general
└ P505.02 NetWordIN1.01 Not acve [0] Selecon list 0x400E:002 general
└ P505.03 NetWordIN1.02 Quick stop [3] Selecon list 0x400E:003 general
└ P505.04 NetWordIN1.03 Not acve [0] Selecon list 0x400E:004 general
└ P505.05 NetWordIN1.04 Run forward [8] Selecon list 0x400E:005 general
└ P505.06 NetWordIN1.05 Setp: Preset b0 [18] Selecon list 0x400E:006 general
└ P505.07 NetWordIN1.06 Setp: Preset b1 [19] Selecon list 0x400E:007 general
└ P505.08 NetWordIN1.07 Reset error [4] Selecon list 0x400E:008 general
└ P505.09 NetWordIN1.08 Not acve [0] Selecon list 0x400E:009 general
└ P505.10 NetWordIN1.09 DC braking [5] Selecon list 0x400E:010 general
└ P505.11 NetWordIN1.10 Not acve [0] Selecon list 0x400E:011 general
└ P505.12 NetWordIN1.11 Not acve [0] Selecon list 0x400E:012 general
└ P505.13 NetWordIN1.12 Reverse rot.dir. [13] Selecon list 0x400E:013 general
└ P505.14 NetWordIN1.13 Not acve [0] Selecon list 0x400E:014 general
└ P505.15 NetWordIN1.14 Not acve [0] Selecon list 0x400E:015 general
└ P505.16 NetWordIN1.15 Not acve [0] Selecon list 0x400E:016 general
P508.00 CANopen comm. No acon [0] Selecon list 0x2300 CANopen
P508.00 EtherCAT comm. No acon [0] Selecon list 0x2360 EtherCAT
P508.00 EtherN/IP comm. No acon [0] Selecon list 0x23A0 EtherNet/IP
P508.00 Modbus comm. No acon [0] Selecon list 0x2320 Modbus RTU
P508.00 MBTCP comm. No acon [0] Selecon list 0x23B0 Modbus TCP
P508.00 PROFINET comm. No acon [0] Selecon list 0x2380 PROFINET
P509.00 CANopen switch - - (Read only) 0x2303 CANopen
P509.00 EtherC. switch - - (Read only) 0x2363 EtherCAT
P509.00 EtherN. switch - - (Read only) 0x23A3 EtherNet/IP
P509.00 Modbus switch - - (Read only) 0x2323 Modbus RTU
P509.00 Switch posion - - (Read only) 0x23B3 Modbus TCP
P509.00 PROFIBUS switch - - (Read only) 0x2343 PROFIBUS
P510.xx CANopen se.
└ P510.01 Node ID 1 1 ... 127 0x2301:001 CANopen
└ P510.02 Baud rate 500 kbps [5] Selecon list 0x2301:002 CANopen
└ P510.03 Slave/Master Slave [0] Selecon list 0x2301:003 CANopen
└ P510.04 Start rem. delay 3000 ms 0 ... 65535 ms 0x2301:004 CANopen
└ P510.05 SDO2 channel Not acve [0] Selecon list 0x2301:005 CANopen
└ P510.06 COB-ID Cong Base + node-ID [0] Selecon list 0x2301:006 CANopen
P510.xx EtherCAT se.
└ P510.04 Device ident. 0 0 ... 65535 0x2361:004 EtherCAT
P510.xx EtherN/IP se.
└ P510.01 IP address 276605120 0 ... 4294967295 0x23A1:001 EtherNet/IP
└ P510.02 Subnet 16777215 0 ... 4294967295 0x23A1:002 EtherNet/IP
└ P510.03 Gateway 0 0 ... 4294967295 0x23A1:003 EtherNet/IP
└ P510.04 Host name Text 0x23A1:004 EtherNet/IP
└ P510.05 IP conguraon BOOTP [1] Selecon list 0x23A1:005 EtherNet/IP
└ P510.06 Mulcast TTL 1 1 ... 255 0x23A1:006 EtherNet/IP
└ P510.07 Mcast allocaon Default alloc. [0] Selecon list 0x23A1:007 EtherNet/IP
└ P510.08 Mcast IP addr. 3221373167 0 ... 4294967295 0x23A1:008 EtherNet/IP
└ P510.09 Mulcast number 1 1 ... 8 0x23A1:009 EtherNet/IP
└ P510.10 Timeout 10000 ms 500 ... 65535 ms 0x23A1:010 EtherNet/IP
P510.xx Modbus se.
└ P510.01 Node ID 1 1 ... 247 0x2321:001 Modbus RTU
└ P510.02 Baud rate Automac [0] Selecon list 0x2321:002 Modbus RTU
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
95
