19
Commissioning
Operang Instrucons i550-Cabinet
7.1.1 Funconsofthekeys
Key Actuaon Acon
Press briey Navigaon in the menu
Parameter alteraon
Press briey Go to Menu/Parameters
Conrm parameter
Press and hold for 3s Save parameters
“P.SAVED” in the display indicates that the parameters have been saved
Press briey Quit Menu/Parameters
Press briey Acvate keypad control
Press briey Start motor
Press briey Change rotang direcon
Press briey Stop motor
The motor must be at standsll before parameters can be changed or conrmed.
The sengs are saved temporarily unl the motor is switched o again. To save the sengs
permanently, press and hold the key
for 3 s.
7.1.2 Example of the keypad handling
Example for DO1 funcon assignment with parameter P420.02.
GROUP 4
P420.XX
P420.02
I/O setting
Fct. dig. outputs
DO1 funcon
7.1.3 Quickcommissioning-terminalcontrol
The following quick overview with graphical parameter representaon is sucient for com-
missioning many applicaons with terminal control. Further seng opons are described in
this document or in the commissioning document.
1. Load default seng = Set P700.01 to 1.
2. Set the following parameters for V/f characterisc control:
Mains voltage P208.01
V/f characterisc data: Base voltage P303.01
V/f characterisc data: Base frequency P303.02
Minimum frequency P210.00
Maximum frequency P211.00
Acceleraon me 1 P220.00
Deceleraon me 1 P221.00
Analog input 1: Min frequency value P430.02
Analog input 1: Max frequency value P430.03
3. Press and hold the key
longer than 3 seconds in order to save the sengs.
P211.00
P430.03
P430.02 P430.02
P220.00
P221.00
P210.00
A
I1
Time
Frequency
