Lenze m550-H-P63 80 Series - Preparation

Thread M6 M8 M10 M12 M16 M20 M24
Load carrying
capacity
kg 80 140 230 340 700 1200 1800
Preparaon
•
Protect sha sealing rings from contact with solvents.
•
Remove protecon covers from shas.
•
Thoroughly remove ancorrosion agents from the sha and from ange faces.
•
Draw the transmission elements onto the output sha only by using the centering thread.
•
Align the output sha and transmission elements exactly to avoid tensions.
•
Mount belt pulleys, sprockets, or gear wheels as close as possible to the sha shoulder in
order to keep the bending load of the sha and the bearing forces at a minimum level.
•
Tighten all screw connecons with the specied torques and secure them with standard
screw locking adhesive.
•
Check paint for damage and repair professionally.
Thread M3 M4 M5 M6 M8 M10 M12 M16 M20 M24 M27 M30
Strength Tightening torque Nm ±10 %
4.8 Nm 0.7 1.4 2.8 4.8 12 23 − − − − − −
8.8 Nm 1.3 3.0 5.9 10.1 24.6 48 84 206 415 714 1050 1428
10.9 Nm 1.9 4.6 8.6 14.9 36.1 71 123 302 592 1017 1496 2033
Mechanical installaon
Preparaon
21
