Lenze MCS 06I41 - 400 V Forced-Ventilated Motor Data (Part 3)

Motor MCS 14P26- MCS 14P11- MCS 19F29- MCS 19F12- MCS 19J29- MCS 19P29-
Standsll torque M
0
Nm 43.5 43.5 41.5 41.5 70.5 86.0
Rated torque M
rated
Nm 33.0 42.0 32.5 38.0 50.5 53.0
Max. torque M
max
Nm 105 105 86.0 86.0 129 190
Rated speed n
rated
rpm 2625 1050 2850 1200 2850 2850
Max. speed n
max
rpm 6000 6000 4000 4000 4000 4000
Rated power P
rated
kW 9.1 4.6 9.7 4.8 15.1 15.8
Standsll current I
0
A 28.3 14.1 24.5 12.2 40.6 44.7
Rated current I
rated
A 21.9 13.4 20.1 11.3 31.0 29.5
Max. current I
max
A 92.0 46.0 62.5 31.3 89.6 120
Rated voltage V
rated
V 325 330 320 320 315 315
Rated frequency f
rated
Hz 175 70 190 80 190 190
Moment of inera J kgcm² 34.7 34.7 65.0 65.0 105 160
Eciency η 0.92 0.86 0.95 0.9 0.93 0.93
Torque constant Kt
0 150
°C
Nm/A 1.54 3.09 1.69 3.40 1.74 1.92
Voltage constant KE
LL 150
°C
V/
(1000/
min)
87.41 175.02 95.04 190.66 97.29 105.6
Stator terminal resistance R
UV 20
°C
Ω 0.28 1.2 0.32 1.3 0.16 0.14
Stator terminal resistance R
UV 150
°C
Ω 0.422 1.808 0.482 1.959 0.241 0.211
Stator inductance L mH 5.99 23.9 5.20 20.8 3.20 2.40
Weight m kg 29.7 29.7 30 30 37 47
Technical data
Rated data
Inverter power supply 400 V, forced venlated motors
