Product description
Identification
Nameplate
3
l
13
BA 13.0011−EN 1.0
1 General information
1.1 Manufacturer 1.2 Applicable conformity declarations and approvals
2 Data on the complete drive system
2.1 Drives 2.2 Type of drive
3 Inverter data
3.1 Inverter 3.6 Voltage / I=I
max
3.2 Type of inverter 3.7 Fieldbus
3.3 FW 3.8 RS232
3.4 HW 3.9 I/O
3.5 Input
4 Encoder data
4.1 Encoder / feedback 4.3 Encoder voltage
4.2 Type of encoder 4.4 Indicated voltage
5 Gearbox data
5.1 Gearbox 5.4 Ratio
5.2 Gearbox type 5.5 Lubricant
5.3 Torque M
2
[Nm] 5.6 Type of lubricant
6 Motor data
6.1 Motor 6.9 n
max
(mechanical)
6.2 Motor type 6.10 C86 code
6.3 Motor type 6.11 Circuit, rated voltage
6.4 Rated power [kW] 6.12 Rated frequency
6.5 Degree of protection 6.13 Rated current
6.6 Rated torque 6.14 Rated speed
6.7 Operating mode 6.15 Insulation class of the winding
6.8 cos j 6.16 Temperature sensor
7 Brake data
7.1 Brake 7.3 Voltage, current, braking torque
7.2 Type of brake 7.4 Material number
8 Production data
8.1 Customer order number 8.4 Serial number
8.2 Year of manufacture 8.5 Bar code
8.3 Ident no. of the drive
