Page #9 background imageLoading...
Page #9 background image
7
EDBSV571 EN 1.0
EN
Technical Data
2.2 SMV Type Number Designation
The table herein lists the SMVector Inverter models used in CaptiveAire systems.
CaptiveAire Model # Mains Voltage Hp kW
ESV751N01SXB571 120 VAC, 1-phase 1.0 0.75
ESV112N01SXB571 120 VAC, 1-phase 1.5 1.1
ESV371N02YXB571 240 VAC, 1- / 3-phase 0.5 0.37
ESV751N02YXB571 240 VAC, 1- / 3-phase 1.0 0.75
ESV112N02TXB571 240 VAC, 3-phase 1.5 1.1
ESV112N02YXB571 240 VAC, 1- / 3-phase 1.5 1.1
ESV152N02YXB571 240 VAC, 1- / 3-phase 2.0 1.5
ESV222N02YXB571 240 VAC, 1- / 3-phase 3.0 2.2
ESV402N02TXB571 240 VAC, 3-phase 5.0 4.0
ESV552N02TXB571 240 VAC, 3-phase 7.5 5.5
ESV752N02TXB571 240 VAC, 3-phase 10 7.5
ESV751N04TXB571 480/400 VAC, 3-phase 1.0 0.75
ESV112N04TXB571 480/400 VAC, 3-phase 1.5 1.1
ESV152N04TXB571 480/400 VAC, 3-phase 2.0 1.5
ESV222N04TXB571 480/400 VAC, 3-phase 3.0 2.2
ESV402N04TXB571 480/400 VAC, 3-phase 5.0 4.0
ESV552N04TXB571 480/400 VAC, 3-phase 7.5 5.5
ESV752N04TXB571 480/400 VAC, 3-phase 10 7.5
ESV751N06TXB571 600 VAC, 3-phase 0.5 0.37
ESV152N06TXB571 600 VAC, 3-phase 2.0 1.5
ESV222N06TXB571 600 VAC, 3-phase 3.0 2.2
ESV402N06TXB571 600 VAC, 3-phase 5.0 4.0
ESV552N06TXB571 600 VAC, 3-phase 7.5 5.5
ESV752N06TXB571 600 VAC, 3-phase 10 7.5
NOTE
Prior to installation make sure the enclosure is suitable for the end-use environment
Variables that influence enclosure suitability include (but are not limited to)
temperature, airborne contaminates, chemical concentration, mechanical stress
and duration of exposure (sunlight, wind, precipitation).
