FUNCTION 10: CELSIUS OUTPUT
When activated, this mode displays the air
temperature in Celsius. If Celsius is activated, the
Fahrenheit Mode and LOS (Line of Sight) range
will be disabled. The output is displayed in smaller
numbers just below and to the right of the reticle.
FUNCTION 11: DIGITAL COMPASS MODE (RX-IV ONLY)
When this mode is activated, the compass heading will
be displayed in larger numbers above the reticle. If the
Digital Compass Mode is activated, the True Ballistic
Range (TBR) will be disabled. The compass will perform
accurately even if tilted for viewing targets up or
down hill, up to a 30° slope. This tilt compensation
is accomplished via a sophisticated computer processed
algorithm that incorporates both the compass and inclinometer readings.
12
